Table 11.3 Logix 3400IQ-011 : AO-011 (AO)
Configuration File Data
(1) ST_REV = 0x0002
(2) TAG_DESC =
(3) STRATEGY = 0x0000
(4) ALERT_KEY = 0x00
(5) MODE_BLK =
TARGET = Auto
ACTUAL = Auto
PERMITTED = RCas | Cas | Auto | Man | OOS
NORMAL = Auto
(6) BLOCK_ERR = 0x0000
(7) PV =
S TATUS = Good_NonCascade::UnacknowledgedBlockAlarm:
NotLimited
VALUE = 82.78
(8) SP =
STATUS = Good_Cascade::NonSpecific:NotLimited
VALUE = 83.04
(9) OUT =
STATUS = Good_Cascade::NonSpecific:NotLimited
VALUE = 0
(10) SIMULATE =
SIMULATE_STATUS = Bad::NonSpecific:NotLimited
SIMULATE_VALUE = 0
T RANSDUCER_STATUS = Good_Cascade::NonSpecific:
NotLimited
TRANSDUCER_VALUE = 0
ENABLE_DISABLE = Un-initialized
(11) PV_SCALE =
EU_100 = 100
EU_0 = 0
UNITS_INDEX = 0x0000
DECIMAL = 0x00
(12) XD_SCALE =
EU_0 = 0
UNITS_INDEX = 0x0000
DECIMAL = 0x00
(13) GRANT_DENY =
GRANT = 0x00
DENY = 0x00
(14) IO_OPTS = 0x0000
(15) STATUS_OPTS = 0x0000
(16) READBACK =
STATUS = Good_NonCascade::NonSpecific:NotLimited
VALUE = 82.78
Logix 3400IQ Digital Positioner FCD LGENIM3402-00 – 0/07
Comments
Block tagname (Analog output)
(index) parameter mnemonic = value
