Warnings

• Not to be used horizontally�
• The product is NOT to be opened by unauthorised personel�
• Always check correct assembly after mounting and service to ensure that the cable locks are mounted�
• Ensure that the cable cannot be squeezed, pulled or subjected to any other stress or damages�
• LC3 IC is heavy (more than 20 kg)� To avoid personal injury and product damage, DO NOT DROP!
• Take special precautions concerning 3
information�
• Do not adjust anything during movement or while connected to mains, as it can cause personal injury�
• To avoid cable interruption and column defects, make a proper cable installation and inspect regularly for
wear, damage and jarring sound� Defective parts must be replaced�
• After service inspection, the application must be tested for correct functionality before it is put into
operation� If used in parallel applications, misalignment between two or more columns must be avoided�
• Do not loosen any screws on the LC3 IC, as this can cause collapse of the column!
• All cables must remain plugged in during cleaning to prevent the ingress of water�
• The lifting column can become functional safety systems compliant with EN ISO10218-2� To integrate
the LC3 IC into a functional safety chain, external safety devices such as safety contactors/relays havs to
be implemented�

Recommendations

• Please follow the important LC3 IC mounting guidelines�
• LC3 IC is for use in both push and pull applications, cable outlet from smallest profile (top)�
See top and bottom plate dimensions� The lifting column can be mounted upside down�
• It is recommend to make a functional test of the application with all accessories connected
before putting it into operation�
• Intended for indoor use only�
• Not intended for use in harsh environments like e�g� pool environments, marine environments
and agriculture buildings with ammonia vapors�
• Do not place the column in very dusty environments, since this affects the sliders�
• Listen for unusual sounds and watch out for uneven running during operation� Stop the lifting
column immediately if anything unusual is observed�
party interfacing� If needed, please contact LINAK for further
rd
