2. CONFIGURATION

Indicates the configuration of NCV-30H. Contact your NSD representative for details of ABSOCODER sensor
and the extension sensor cable.
●Connection configuration
1) Converter
Power
Supply
+24V
0V
Ground
Connector at cable side
(It is included in the
converter.)
MR-34F: Soldered socket
MR-34L: Cover
Connectors are manufactured by
Honda Tsushin Kogyo Co., LTD.
3) Extension sensor cable
External output signal
-Position data
-Latch pulse
-System ready
3
PLC
External input signal
-HOLD
-Zero point setting
-Error clear
2) ABSOCODER sensor
Connector
type VLS-8SM20
B
VLS-8SM14
R VLS-8SM14S
Z
