NSD ABSOCODER NCV-30HBNL8 Specifications & Instruction Manual page 11

● Model List
No. Items
1) Converter
Linear type
2) ABSOCODER
sensor
Extension
3)
sensor cable
Models
NCV-30HBNL8
VLS-8SM20-[1]FA[2][L]
VLS-8SM20-[1]LA[2][L]
VLS-8SM14-[1]FB[2][L]
VLS-8SM14S-[1]FB[2][L]
3S-S-0144-[L]
3S-RBT-0144-[L]
3S-URT-0144-[L]
3S-S-4344-[L]
3S-RBT-4344-[L]
3S-URT-4344-[L]
3S-HRT-5152-[L]
3S-S-0190-[L]
3S-RBT-0190-[L]
3S-URT-0190-[L]
3S-S-9044-[L]
3S-RBT-9044-[L]
3S-URT-9044-[L]
3S-HRT-9052-[L]
3S-S-9090-[L]
3S-RBT-9090-[L]
3S-URT-9090-[L]
3S-HRT-9090-[L]
Descriptions
Position data 24-bit binary code output
[1]: Stroke
Flange-mount
VLS-8SM20:
type
50, 100, 150, 200, 250, 300, 350
VLS-8SM14(S):
Base-mount
50, 100, 150, 200
type
[2]: Connector type
Flange-mount
B: Standard connector
type
(NJW-2012PM8, manufacturer:
Nanaboshi Electric Mfg.Co,Ltd.)
Contact your NSD representative
for VLS-8SM14 and VLS-8SM14S.
Flange-mount
R: Crimping terminals (R1.25-4)
type
Z: No connector
[L]: Interconnecting sensor cable
length (m): 2, 5,10, 20
Standard cable, standard connector
Robotic cable, standard connector
Semi-heat-resistant robotic cable, standard connector
Standard cable, standard connector
Robotic cable, standard connector
Semi-heat-resistant robotic cable, standard connector
Heat-resistant robotic cable, standard connector
Standard cable, crimping terminal
Robotic cable, crimping terminal
Semi-heat-resistant robotic cable, crimping terminal
Standard cable, crimping terminal
Robotic cable, crimping terminal
Semi-heat-resistant robotic cable, crimping terminal
Heat-resistant robotic cable, crimping terminal
Standard cable, crimping terminal
Robotic cable, crimping terminal
Semi-heat-resistant robotic cable, crimping terminal
Heat-resistant robotic cable, crimping terminal
