8-2. Settings of the Function Setting Switch

The following two position data reading formats are available:
1) Latch pulse ( LP ) format...Reads position data which is updated regularly in synchronization with a latch
pulse output signal from the converter.
2) HOLD ( HD ) format...Reads position data while position data updates are stopped by a HOLD input signal.
When the LP output signal reading format is used, a position data update period (cycle) can be selected
which is appropriate for the host controller being used.
When the HD input signal reading format is used, either a transparent format or a PC synchro format can be
selected.
The desired position data output format can be select from three formats; binary code, sign magnitude code,
minus zone "0" output.
The position data reading format can be set by the DIP switches on the rear face of the converter.
The DIP switch settings are indicated in the next page.
