Trip Distance
A single tap of the recall button will activate the trip meter in the odometer display. A decimal
point will appear which will indicate that you are in trip meter mode. Holding the recall button will
clear out the trip distance. To return to the default odometer display, tap the recall button again.
The decimal point will disappear, indicating that you are back in the default odometer display.
Setting the Odometer
While scrolling through 'CAL' mode you will see 'ODO' appear. This will allow you to enter the
vehicle's actual mileage. Press the trip button again at this point and you will enter the odometer
set up mode. Press quickly to change the number of the digit on the right. Press and hold to
advance to the next digit. Do this for all 5 digits. For Example: To enter the mileage reading
23456 into the odometer, at the 'ODO' prompt, tap the small black button (quickly) two times,
until the number 2 is dis- played. Then press and hold the button until the numbers 20 are
displayed. Tap the button 3 times until 23 is displayed. Press and hold the button until 230 is
displayed and continue in this manner until 23456 is displayed. The speedometer will advance to
the home screen, five seconds after the last number is entered.
Recording and Viewing Performance Data
Follow these steps to record and recall Performance Data (high speed, ¼mile ET, and 0-60 time):
Before each run, your car must be at a complete stop at the starting position. Press and hold
1.
the pushbutton as it cycles through the performance data. At the end, the odometer will re-set
and all performance data will be cleared. This will not affect your stored calibration value or
the odometer reading.
2. Press the push-button until 'HI-SP' is displayed. The gauge will automatically cycle through
the performance data.
Start the run, pass, session, etc., as mentioned above.
3.
When finished, repeat Step 2 to view the data gathered from the run. While stopped, you
4.
can view this data as often as you wish. However, once it finishes scrolling one time, the
memory is ready to record new data and will begin recording again once the vehicle starts to
move. The highest speed measured over multiple runs will be retained in memory.
SPEEDOMETER CALIBRATION PROCEDURE
Your Intellitronix dash panel is equipped with our Digital Performance Speedometer which
has factory settings that are pre-set with the industry standard setting of 8,000 pulses per
mile to match your vehicles factory settings. This electronic speedometer displays speed
and includes an odometer, trip meter, high speed recall, 0-60 time, and quarter-mile elapsed
time. It can be calibrated with the push-button to adjust the speedometer when you have
Different sizes, wheel sizes, and gear ratios.
The single push-button is used by a quick tap to toggle between odometer and trip meter. The
microprocessor distinguishes between a quick tap and a press and hold which will reset the trip
meter in trip mode or display performance data in odometer mode.
CALIBRATION
The Digital Performance Speedometer leaves the factory with a factory pre-set industry
standard setting of 8,000 pulses per mile. You should not have to recalibrate your
speedometer, unless you have changed the original tire size or the rear end gear ratio.
Also, if using the Intellitronix GPS Sending Unit, (S9021 – not included) the speedometer does
not need to be calibrated.
NOTE: DO NOT attempt to recalibrate your speedometer until after it is working properly,
and you have determined that the speed is consistently incorrect. The calibration procedure
will NOT correct a faulty installation or improper wiring.
