SUPPORTED CONFIGURATIONS
Table 7. Solder Link Settings: Digital Interface
Link Default Function
JP10, 2-3 For the SPI level translators (U4, U5, U6, and U7), select the connection of the ADC SPI data outputs
JP11, from either the ADC pins or ground (default).
JP12,
and JP13
Table 8. Jumper Settings: Internal LDOs
Jumper Default
P6 Disconnected
P9 and P10 Connected
analog.com
Function
Select whether the 2 V on-board supply rail is connected to the AD4080
internal LDO regulators supply pin or not.
Select whether the 1.1 V supply rails are supplied by the on-board LDO
regulators (U34 and U35) or the internal LDO regulators s from the AD4080.
EVAL-AD4080
Comment
Do not change the connection in these
solder links.
Comment
Connect to supply the internal LDO regulators.
Disconnect to stop using the on-board LDO
regulators and use the internal LDO regulators
instead.
