4.6 Chart (continued)
Display Selection – The options are Both Probes, Probe 1, and Probe 2
X-axis – This indicates the time, options includes one minute, one hour, one day, one
week, one month or one year.
Y-axis – The left Y-axis is dedicated to temperature. Either humidity or dewpoint can be
selected for the right Y-axis.
Data Source – The options are Live and Recorded.
If Live is selected the real-time data will be charted for the time indicated on the X-axis.
If Recorded is selected the stored data on the SD card will be charted for the time
indicated on the X-axis.
Alarm Relay Set Points – This option will hide or chart (normal) the set point values.
The bold option will thicken the displayed set point lines.
If Alarm Relays are disabled (in the Configuration menu) the set points for High
and Low alarms will not be graphed or displayed on the chart.
Sensor Type – Choose Humidity or Dewpoint.
Show – To select which probes are charted.
Graph Line Style – Choose between Normal and Bold.
Save Chart – Save the current graph in PNG (Portable Network Graphics) format. The
filename has extension .png. This option will require the Java Policy file to be setup.
Press on Help[?] for details. An alternate way to set up the Java Policy can be found in
Appendix G.
Print Chart – The displayed chart will be printed once the button is clicked.
If you want to access the "Chart" and/or the "Readings" applet from outside your
local network on which the iServer is connected, you must allow ports 1001
(Readings) and 2003 (Chart) on your Router.

4.7 Web Link

This page is configured from the Network menu under IP configuration.
Refer to Section 4.4.2.1.
Web Link
Address http://192.168.1.200
Readings Web Link

Figure 4.35 Web Link

Setup
Web Link
45
