4.4.2.2 Ethernet Port

Ethernet Port
Address http://192.168.1.200
Readings
Overview
Network

Configuration

Management
Security
Recording
System
Diagnostics
Log Out
Auto-Negotiation – It is the link, in terms of speed and duplex, between the iServer and
another Ethernet device like an Ethernet switch.
If Auto-Negotiation box is checked, the iServer will auto-negotiate the speed and duplex
with the attached Ethernet device. If any of the other options are selected, the speed
and duplex will be fixed.
It's important to have the same Ethernet port configuration on the iServer and the
attached Ethernet device. If iServer cannot auto-negotiate with the attached Ethernet
node it will default to 10 Mbps and Half-Duplex. Once Auto-Negotiation is checked, other
fields under this category will be dimmed. By default the Auto-Negotiation is checked.
If the iServer detects the link to be 100 Mbps the 100 BASE-T LED will be solid
green.
4.4.3 Configuration
This menu provides configurations for the real-time clock, server parameters, sensors,
and alarm relays settings. Fields are described below.
4.4.3.1 Date and Time
Current Date – This field indicates the iServer's real time clock date. The format is yyyy/
mm/dd. When there is no date defined, the iServer will be defaulted to 2099/01/01 and
be shown in red to alert you that it has not yet been set.
Current Time – This field indicates the iServer's real time clock time. The format is
military time (24-hour) and it is entered as hh:mm:ss.
Change Date and Time – By clicking on this option the real data and time can be entered.
Web Link
IP Configuration
Auto-Negotiation
Speed
Duplex

Figure 4.14 Network: Ethernet Configuration

Setup
Ethernet Port
100 Mbps
Full
Save Changes
23
10 Mbps
Half
Reset
