NoTeS, WARNINGS and cAUTIoNS Information that is especially important to note is identified by the following labels: • NOTE • WARNING or CAUTION • IMPORTANT • TIP NOTE: Provides you with information that is important to successfully setup and use the iServer. CAUTION or WARNING: Tells you about the risk of electrical shock.
Web Browser. The iBTHX is for barometric pressure, temperature, relative humidity and dew point. The iBTX is for barometric pressure and temperature. The difference between the iBTHX and the iBTX is only the probe/sensor. The iServer serves Active Web Pages to display real time readings, display charts of barometric pressure, temperature and humidity, or log data in standard data formats for use in a spreadsheet or data acquisition program such as Excel or Visual Basic.
Page 7
PDA’s. This device can be purchased as a stand alone DIN Rail mounted unit (iBTX-D or iBTHX-D), as a bench/wall mount unit (iBTX-W or iBTHX-W), or as a bench/wall mount unit with an LCD display, Flash Memory Card and Back-up Battery (iBTX-SD).
PART 2 HARdWARe 2.1 Mounting 2.1.1 Mounting the Wall Mount iServer Position unit where required. Mark and drill the two #6 screw holes. After bracket is mounted on the wall, align back of unit over the three bracket clips, once engaged, slide downward, the unit will snap in place.
2.1.2 Mounting the DIN Rail iServer To install unit onto DIN Rail: a) Tilt unit, position mounting slot onto DIN Rail, as shown. b) Push unit towards DIN Rail and it will snap into place. Figure 2.2 Mounting - DIN Rail iServer 2.1.3 Removal from a DIN Rail a) Insert flat screw-driver into tab and push downwards.
2.2 DIP Switches 2.2.1 DIP Switch Usage The iServer is shipped with all DIP switches in "OFF" position. N/C - not used To change to default factory settings To enable/disable DHCP N/C - not used To set the iServer to factory default settings, slide DIP switch #2 to ON position. Power the iServer on and wait about 10 seconds until the iServer fully boots up.
/ iBTX-D Pin# Top Connector Data In (B) Orange CLK (B) Blue SCK (H)* Red/Blk Data (H)* Wht/Blk iBTHX-W / iBTX-W DB9 Pin # Bottom Connector Pin# Signal Pin# Signal 3.3V Data Out (B) Data In (B) White CLK (B)
2.4 Network Communication Interfaces 2.4.1 10Base-T RJ-45 Pinout The 10BASE-T Ethernet network (RJ-45) system is used in the iServer for network connectivity. The 10 Mbps twisted-pair Ethernet system operates over two pairs of wires. One pair is used for receiving data signals and the other pair is used for transmitting data signals.
PART 3 NeTWoRk coNFIGURATIoN 3.1 Network Protocols The iServer can be connected to the network using standard TCP/IP protocols. It also supports ARP, HTTP (WEB server), DHCP, DNS and Telnet protocols. 3.2 Ethernet (MAC) Address MAC (Media Access Control) address is your computer's unique hardware number. When you're connected to the LAN from your computer, a correspondence table relates your IP address to your computer's physical (MAC) address.
3.3 DHCP DHCP, Dynamic Host Configuration Protocol, enables computers and network devices to receive their IP configurations from a DHCP server. If DHCP is enabled on your iServer, as soon as the iServer that is connected to the network is powered on, there will be an exchange of information between the iServer and the DHCP server.
3.5 Default IP Address The iServer is shipped with a default IP address of 192.168.1.200 and Subnet Mask of 255.255.255.0. If you are going to use a Web browser or Telnet program to access the iServer using its default IP address, make sure that the PC from which you’re establishing the connection has an IP address that is in the same range as the iServer’s IP address (192.168.1.x, where x can be any number from 1 to 254.
PART 4 oPeRATIoNS This iServer can be used and configured in several ways, depending on user’s preference and network setup. It can be configured using a Web browser, like Netscape or Internet Explorer. It can also be configured using iConnect Configuration Software. If DHCP and DNS servers are used, the connection is very simple, no need to find the right IP address or watch for network conflicts, these are all done for you by your network DHCP and DNS server.
4.1 iConnect Software The iServer may also be assigned an IP Address by using the iConnect software. Download the iConnect software from the website listed in this manual. Install iConnect software on a networked PC. This software is compatible with Windows 95, 98, NT, 2000, and XP. Use iConnect to assign an IP address to the iServer and access its web pages for configuration.
Page 18
4.1 iConnect Software (continued) To access the iServer for Configuration: Click on the “View Webpage” button, you will access the iServer’s home page, refer to Section 4.3 for details. iSERVER HOME PAGE Read Sensor Chart Access Control Configuration Figure 4.3 Accessing the iServer’s Home Page Menu...
4.2 Setting a New IP Address over the Network Besides using the iConnect software, you may use the iServer’s default IP address to access it and assign a new IP address to it. The iServer is shipped with a default IP address of 192.168.1.200 and Subnet Mask of 255.255.255.0.
4.3 Setup and Operation Using a Web Browser • Start your web browser. • From the browser you type http://eisxxxx using the last four-digits from the MAC address label located on the device if DHCP and DNS are used. If a static IP address is used, then simply type http://x x x x, where x x x x is the iServer’s IP address.
Customer Service Department nearest you. Read Sensor http://192.168.1.200 Title Temperature 90.5 Pressure 1007.8 mbar If you have an iBTX: Humidity and Humidity 36.6 % Dewpoint are not displayed Dewpoint 53.6 Main Menu Figure 4.7 Read Sensor...
4.3.1.2 Java Runtime Environment 1.5 (5.0) Setup instructions 1. Go to your computer's Control Panel. Open the Java Plug-in 2. Click on "Settings" & "View Applets" in the "General" tab. 3. Select the "Settings" button on the General Tab Un-check the "Enable Caching" box. Then close dialog box to show the General Tab again 4.
1 week, 1 month, or 1 year Figure 4.8 Chart If you have an iBTX model, the probe will only sense Temperature and Pressure; to indicate this, the Humidity and Dewpoint boxes on the chart will switch between OPEN and a false number.
4.3.3 Configuration Configuration • Click on , the following page should appear. CONFIGURATION http://192.168.1.200 CONFIGURATION Display Display Remote Remote End Char Device Name Reading Offset Units Format Format (HEX) Temperature SRTF decimal T00.0F 0000.0 Pressure SRHb mbar decimal P0000.0B 0000.0 Humidity SRH2 decimal...
Page 25
4.3.3 Configuration (continued) B) Terminal Server TCP/UDP*: The iServer supports TCP and UDP protocols (default is TCP). If UDP is selected, it can be configured either for Broadcast UDP or Directed UDP. In case of Broadcast UDP, the iServer will transmit the data to every node on the network. This can be accomplished if the Remote IP Address is set to 255.255.255.255.
4.3.4 Sensor Parameters (continued) Remote Display Format: Remote display format is used for Terminal Server continuous mode. This determines the data format sent by the iServer to a remote network node (e.g. iLD Display) H37.9% in humidity setting displays H, and 37.9% is the humidity value displayed. Example: if the humidity is 37.9, then H37.9% will be seen on the remote display.
4.3.5 Configure Access Control (continued) Access Control http://192.168.1.200 ACCESS CONTROL Login Password: 12345678 Admin Password: 00000000 Host Name: eis0e0f MAC Address: 0A:0B:0C:0D:0E:0F IP Address: 192.168.1.200 0.0.0.0 Gateway Address: 255.255.255.0 Subnet Mask: Save Reset Power Recycle Main Menu Figure 4.12 Access Control Login Password: This allows users to access and modify all of the iServer Home Page menu items, except “Access Control”, which requires an Administrator password.
4.3.5 Configure Access Control (continued) Gateway Address: A gateway is a network point that acts as an entrance to another network. A gateway is often associated with a router, which knows where to direct a given packet of data that arrives at the gateway. If the iServer is sending packets to another network node that is not on the same network on which the iServer is connected, a gateway address needs to be given to the iServer.
4.5.1 HTTPget using Port 1000 You can setup and read the information from the iServer by using the HTTPget program. The following program can be used to read data from the iServer firmware by using TCP port 1000. The command string is sent to this TCP port, then the response can be read back from the same socket.
4.5.2 HTTPget and ARP to setup Device IP Address Use the iConnect software, which may be downloaded from our website, to do these IP changes whenever possible. Use ARP first to assign the mac address to a static IP address in computer arp table by this command: arp –s 192.168.1.200 00-03-34-00-06-b6 Then use the following command to assign new IP to the device:...
4.6 ARP Protocol (continued) The following window shows examples of arp commands and responses. • Your computer has an IP address of 192.168.1.118 • The destination computer has an IP address of 192.168.1.96 C:\>arp - 192.168.1.96 No ARP Entries Found C:\>ping 192.168.1.96 Pinging 192.168.1.96 with 32 bytes of data: Reply from 192.168.1.96=bytes=32 time=5ms TTL=32...
4.7 Remote Access (Tunneling) To "tunnel", in this context, is to transmit data between two points through a private conduit on a shared or public network. The network could be an Ethernet LAN, a WAN, or the Internet. There is a Serial-to-Ethernet iServer that allows for a connection between a serial device and a PC, or between two serial devices, using an existing network rather than dedicated wiring.
4.7.1 Local iServer 1. An IP address should be assigned to the iServer dynamically or statically (recommended). 2. Use a browser to access the Local iServer’s WEB page. Simply type the iServer’s IP address at the browser’s URL location (i.e. 192.168.1.49) followed by an Enter key. You should then see the iServer’s main WEB page.
4.7.2 Remote iServer 1. An IP address should be assigned to the iServer either statically or using a DHCP server. Refer to the DHCP section of the user’s manual for details. Use a browser to access the Remote iServer’s WEB page. Simply type the iServer’s IP address at the browser’s URL location (i.e.
4.8 iLog Software This is an Excel application software that can log temperature, humidity and dewpoint from the iServer over the local network (Ethernet) or the internet. Download the iLog software from the website listed in this manual. Install iLog software on a networked PC. This software is compatible with Windows 95, 98, NT, 2000, XP, and Vista.
4.9 Mail Notifier Software The Mail Notifier Software can be used only with NEWPORT Electronics instruments. For complete information of how to use the Mail Notifier software, click on the Help menu of the main window. The Mail Notifier software generates email notifications for alarm conditions. Users can be notified automatically of alarm conditions monitored via internet connections throughout the world.
4.9.2 Program Options Setup and Configuration Complete program setup requires: Options • Entering a recipient for Send To Email Setup Content Startup General the email Mail Server • Specifying connection details to MAPI services. MAPI • Defining alarms for devices, Use Login Name/Profile and selecting how and when...
4.9.3 Device Setting and Configuration Device setup requires: • Entering the IP address for iServer device (for example 192.168.1.200). • Specifying Socket number (1000 or 2000 depending on iServer settings). • Defining RS485 Unit # interface address (1 to 199). Enter "0" for RS232 interface or for iServer.
PART 5 SPecIFIcATIoNS SeNSoR SPecIFIcATIoNS BARomeTRIc PReSSURe (iBTX, iBTHX) Accuracy/Range: ±2.0 mbar / 10 to 1100 mbar (1 to 110 KPa) Resolution: 0.1 mbar ReLATIVe HUmIdITY (iBTHX) Accuracy/Range: ±2% for 10 to 90% ±3% for 5 to 10% and 90 to 95% ±4% for 0 to 5% and 95 to 100%...
Page 42
9 to 12 Vdc iBTHX/iBTX-W 10 to 32 Vdc iBTHX/iBTX-D Safety Qualified (included) ac power adapter: Nominal Output: 9 Vdc @ 0.5A; Input: 100 to 240Vac, 50/60 Hz included for iBTHX/iBTX-W Switching Power Supply: Sold separately for iBTHX/iBTX-D Consumption: 2.5 W max.
Page 43
PAckAGING 3.55 [90.2] 2.60 [66.0] 3.05 [77.5] 2.42 [61.6] 0.25 [6.4] 3.56 3.67 [90.3] [93.1] 0.25 [6.4] 0.14 [3.6] 0.30 1.78 [45.2] [7.7] 0.82 1.08 0.88 0.93 [20.8] [ 27.4] [ 22.4] [23.6] Version A - new case style Version B - older case style Version A Version B Figure 5.1 Wall Mount iServer Dimensions...
PART 6 FAcToRY PReSeT VALUeS PRESET PARAMETERS FACTORY DEFAULTS Network Interface: IP Address 192.168.1.200 Gateway Address 0.0.0.0 Subnet Mask 255.255.255.0 Device Host Name eis and last 4 digits from the MAC address Login Password 12345678 Admin Password 00000000 DHCP Disabled End Character 0D (Hex) (Carridge Return) Terminal Server:...
Appendix A GLoSSARY User of this manual should be familiar with following definitions: ARP (Address Resolution Protocol) is a protocol for mapping an Internet Protocol address (IP address) to a physical machine address that is recognized in the local network. For example, the IP address in use today is an address that is 32-bits long.
Appendix B IP Address An IP address is a unique 32-bit address assigned to a computer and includes: • A network ID number identifying a network. • A host ID number identifying a computer on the network. All IP addresses have been divided into three smaller groups (classes) A, B and C •...
Appendix c IP Netmask IP Netmask or Subnet Mask is a 32-bit pattern of ones and zeros used to determine network portion of an IP address from the host portion of the IP address. Subnet mask is a network ID that is created by borrowing bits from host portion of IP address and using them as part of a network ID.
Appendix e iLog error messages Error # Description Note -8003 User stopped logging readings. -10005 Failed to find the iServer. Ethernet cable is disconnected, iServer is powered off, connections across the firewall require longer “connection to socket time out” setting. -10006 Windows socket was closed.
Appendix F Sensor Information F.1 Accuracy Figure F.1 Figure F.2 RH Accuracy Chart Temperature Accuracy Chart Accuracies are tested at Manufacture’s Outgoing Quality Control at 25°C (77°F) and 3.3V. Values exclude hysteresis and non-linearity, and is only applicable to noncondensing environments.
Page 52
Appendix F Sensor Information (continued) F.4 Reconditioning Procedure As stated above extreme conditions or exposure to solvent vapors may offset the sensor. The following reconditioning procedure may bring the sensor back to calibration state: Baking: 100 – 105°C at < 5%RH for 10h Re-Hydration: 20 –...
PART 7 APPRoVALS INFoRmATIoN 7.1 CE APPROVAL This product conforms to the EMC directive 89/336/EEC amended by 93/68/EEC, and with the European Low Voltage Directive 72/23/EEC. Electrical Safety EN61010-1:2001 Safety requirements for electrical equipment for measurement, control and laboratory. Basic Insulation Pollution Degree 2 Dielectric withstand Test per 1 min •...
Page 57
WARRANTY/dIScLAImeR OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of one (1) year from the date of purchase. In addition to OMEGA’s standard warranty period, OMEGA Engineering will extend the warranty period for one (1) additional year if the warranty card enclosed with each instrument is returned to OMEGA.
