4.4.6 Recording

This section includes all the parameters and settings for data recording, SD flash card
and recording status, data retrieval, and formatting the SD card.
Fields are described below.

4.4.6.1 Start Recording

Start Recording
Address http://192.168.1.200
Readings
Start Recording
Current Date:
Overview
Network
Interval
Configuration
Management
Security
Type
Recording
System
Set Date and Time
Diagnostics
Start Date
Log Out
Stop Date
Set Weekdays (only for scheduled recording)
Interval – This is the time interval between each data. It can be between 1 to 3600
seconds.
Title – This is the header for each recorded data file on the SD flash card.
Quick Start Recording – If this button is clicked recording will start immediately.
Make sure your Current Date and Time are correct.
Type – The options are Wrap and Non-Wrap.
If Wrap is selected once the SD flash card is full the iServer will delete the old data
stored on the card in order to record the new data. Each time a new recording takes
place an old record will be deleted.
If Non-Wrap is selected the iServer will stop recording once the SD flash card is full.
Web Link
Status Data Retrieval
2099/01/01
10 (1-3600)seconds
Wrap
yyyy/mm/dd
yyyy/mm/dd
Mon Tue Wed

Figure 4.22 Recording Menu: Start Recording

Setup
Format SD Card
(yyyy/mm/dd) Current Time:
Title
Category
Start Time
Stop Time
Thur
Start Recording
34
00:00:00
Quick Start Recording
Continuous
hh:mm:ss(24 hours)
hh:mm:ss(24 hours)
Fri Sat Sun
