Setting Up Streaming

From the Outputs pages, you can set up streaming. On the Makito X with Storage, you can set up
streaming only, recording only, or streaming with recording.
1. Click Outputs on the sidebar (under General Settings).
2. On the Outputs List View, click Add to create the first stream or recording session.
3. On the New Stream page, fill in the fields to choose the Content:
4. Type a name for the stream in the Name field.
5. For the Source, (as an example) use Video Encoder
Metadata.

Note
By default, SDI Input 1 is assigned to Video Encoders
to Video Encoders
6. (Makito X with Storage only) To set up streaming, toggle the Streaming Parameters button to On.
7. For a basic MPEG-2 transport stream setup, under Broadcasting, select TS over UDP as the
Protocol (keeping the default TS settings).
8. Under Destination, type in the IP Address and Port number, for example, multicast address
and port
225.6.7.8
9. Leave the default values for the remaining Streaming parameters.
the User's Guide.
Makito X Encoder 2.2
Makito X Encoder Quick Start Guide
and .
2 3
.
2000
0 and Audio Encoder
and
0 1
See Streaming Output Settings
9
