DES-3228PA Embedded Web System User Guide

System LEDs

The DES-3228PA system LEDs located on the left side of the device. The following figure illustrates the DES-
3228PA system LEDs.
Figure 5: DES-3228PA System LEDs
The LED indications are described in the following table:
Table 5: System LEDs
LED Des cription
MS
PWR MAX
RPS
FAN
PWR
Fault
LED Des cription
In di ca ti o n
Red Indicates that the device is designated as the stack master.
Green Indicates that the device is designated as stack member.
Indicates the device is not a stack member, and is currently is
Off
stand-alone mode.
Indicates that the device is operating at the maximum power
Amber
output limit.
Indicates that the device is operating at the normal power
Off
output limit.
Indicates that the device is being powered from a Redundant
Green
Power Supply.
Indicates that the device is being powered from a standard
Off
AC power supply.
Amber Indicates that there is a faulty fan.
Green Indicates that all fans are functioning correctly.
Green Indicates that the device is powered up.
Off Indicates that the device is off.
Red Flashing Indicates that the device is currently running POST.
Red Indicates that the device detected a POST running error.
Page 13
