WARNING!
Stored Energy Hazard! This product contains a spring mechanism which can cause the mounted display
to move forcibly, and quickly, upwards. Always exercise caution when adjusting the position of, or in close
proximity to, the mounted display. Do not remove the mounted display unless the spring mechanism is
locked or rendered safe. Failure to do so may result in property damage and/or serious personal injury.
Place the Lever Back Plate onto its receptacle on Monitor
2.
Column Lift, aligning all four holes . Then, using M4x6mm
Screws (x4) and the 5mm Hex Key with Screwdriver,
fasten the Lever Back Plate to the Monitor Lift Column
by carefully driving the M4x6mm Screws into each of the
mounting holes on the Monitor Column Lift through the
screw holes on the Lever Back Plate. As shown in Figure 2.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.StarTech.com/support
Figure 2
