Shifting

• Always shift gears firmly. When transmission is not firmly shifted, it may jump
out of gear, resulting in loss of control of machine.
• Always stop machine to shift gears. Shifting gears while machine is in motion
can damage transmission.
Auxiliary
Transmission
Shift Lever
5332M-0402-100E

Shifting Between 2WD and AWD (CMX224)

• Always stop machine to shift between 2WD or AWD (all-wheel-drive) modes.
Shifting gears while machine is in motion can damage transmission.
• Use 2WD mode under normal condition.
• Pay attention to the minimum turning radius in AWD mode. In AWD mode,
minimum turning radius is greater than that in 2WD mode.
Operation
1. Stop machine.
2. Move auxiliary transmission shift lever to [H
(high speed)] or [L (low speed)] position firmly.
L
N
NOTE
H
• See Specifications (page 15) for the speed
range in either gear position.
-30-
