Open Date SPRINT MAJOR Operator Instructions Manual page 31

Sprint Major - Digi60
MECHANICAL (continued)
ITEM DESCRIPTION
125 Bracket
126 Brake Strap Clamp
127 Brake Strap Support
128 Core Spring
129 Heater Clamp
130 Pivot Bush
131
132 Thumb Nut
133 Back Disc
134 Front Guard
135 Back Pad
136 Back Pad
137 Adjusting Screw Assembly
138 Back Disc
139 Spacer
140 Washer
141 Spacer
142 Wire Bracket
Additional Spare Parts & Repair Kits
PNEUMATIC
Solenoid valve without fittings
ELECTRONIC
Cartridge heater, 240v, 250w. 2 per machine.
Thermistor probe.
Safety microswitch for door.
"End of foil alarm" sensor (if fitted).
Plug-in printer control card, box mount (horizontal)
115v
230v
REPAIR KITS
Spring set containing all springs plus drive belt
©2023 Open Date Equipment Limited All rights reserved.
REV A
Sprint Major Parts List
STOCK REF.
BRA180125
CLA180126
SUP180127
SPR180128
CLA300129
BUS180130
THU120023
DIS130005
GUA300134
BAC130008
BAC130025
ADJ301008
DIS121009
SPA180139
WAS130068
SPA300141
BRA300142
QTY NOTES
1
1
1
4 (SPR530001 x 12 8mm version)
1
1
1
1
1 For R/H printer only.
1
1
1
1
4
3
2
1
6mm VAL510508, or 8mm VAL510517
HEA501512
THE500521
SWI395008
ALA395021
CPC293507
CPC293506
SPR301001
February 2023
Page 31
