Open Date SPRINT MAJOR Operator Instructions Manual page 29

Sprint Major - Digi60
MECHANICAL
Item numbers refer to those on the assembly drawing. When ordering spare parts please use
the Stock Reference.
ITEM DESCRIPTION
1 Main Body
2 Mounting Bracket
3 Drive Roller
4
5 Hub Assembly
6 Hub Spindle
7 Drive Boss
8 Timing Pulley
9 Pulley
10 Drive Roller Shaft
11 Washer
12 Timing Pulley Assembly
13 Main Shaft
14 Pinch Roller Shaft
15 Pinch Roller Assembly
16 Dancing Bar
17 Roller
18 Wire Clamp
19 Lever
20
21 Roller
22 Spindle
23
24 Dancing Arm
25
26 Brake Strap
27 Spring Post
28
29 Manifold Assembly
30 Spring Post
31 Spring Post
32
33 Spring Post
34
35 Stop
36 Seal Retainer
37 Guide Pin
38 Main Piston
39 Cylinder Barrel
40 Piston Lock Nut
41
42 Fork End Assembly
43 Fork End Roller
44 Dowel
45 Grub Screw
46 Cam
47 Mounting Plate
48 Insulator Plate
49 Heater Block
50 Magnet Clamp
51 Side Locator
52 Door Assembly
53 Hinge Block
54 Wire Clamp
55 Roller Shaft
56 Roller
57 Washer
58 Terminal Block
59 Cheese Head Screw
60 Brake Hub
61 Back Guard
62 Side Guard
©2023 Open Date Equipment Limited All rights reserved.
REV A
Sprint Major Parts List
STOCK REF. QTY
N/A
N/A
DRI180003
HUB185066
SPI180006
DRI180007
PUL300008
PUL180009
SHA180010
WAS180011
PUL301003
SHA300013
SHA180014
PIN185080
DAN180016
ROL180017
CLA620044
LEV180019
ROL180021
SPI180022
DAN180024
BRA180026
SPR130024
MAN301005
SPR180030
SPR180031
SPR180033
STO180035
RET300036
GUI300037
PIS300038
BAR300039
NUT300040
FOR301002
N/A
CAM300046
PLA300047
NS300048
HEA300149
CLA180050
SID180051
DOO301007
HIN300053
CLA620044
SHA180055
ROL180056
WAS180057
CON508101
BRA180060
GUA300061
GUA300062
NOTES
1
1
1
2 Includes item 6.
2
1
1
1
1
1
1
1
1
1 Includes item 69.
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1 Piston/Seal Assembly PIS301006
1
1
1 Includes items 43, 44.
1 Part of item 42.
1 Part of item 42.
1 M8 x 10
1
1
1
1
1
2
1 Includes items 53, 64, 66.
1 Part of item 52.
1
2
2
2
1
2 M2.5x6
1
1
1
February 2023
Page 29
