Sprint Major - Digi60
DIGI-60 Mode Settings For Temperature Tolerance Ranges
The Mode Selector is a Rotary Switch located between the Panel and the Transformer.
Mode 1 (Default)
Temperature Range. -5% to +10% of the set point.
Printer operates on all temperatures.
Fault relays functions within the temperature range of the set point.
(The printer will continue to print when under or over temperature)
Mode 2
Temperature Range. -5% to +10% of the set point.
Printer operates within the temperatures range of the set point.
Fault relays functions within the temperature range of the set point.
Mode 3
Temperature Range. -5% to +5% of the set point.
Printer operates on all temperatures.
Fault relays functions within the temperature range of the set point.
(The printer will continue to print when under or over temperature)
Mode 4
Temperature Range. -5% to +5% of the set point.
Printer operates within the temperatures range of the set point.
Fault relays functions within the temperature range of the set point.
Mode 5
Temperature Range. –10% to +10% of the set point.
Printer operates on all temperatures.
Fault relays functions within the temperature range of the set point.
(The printer will continue to print when under or over temperature)
Mode 6
Temperature Range. –10% to +10% of the set point.
Printer operates within the temperatures range of the set point.
Fault relays functions within the temperature range of the set point.
Mode 7, 8, 9 and 0 are the same as the default value. (Mode 1)
©2023 Open Date Equipment Limited All rights reserved.
REV A
February 2023
Page 13
