Open Date SPRINT MAJOR Operator Instructions Manual page 12

Sprint Major - Digi60 REV A February 2023
Setting Up DIGI-60 Controller
Mains Fuse (FS1)
2.0 Amp, 250 Volt (Anti-Surge)
(Part No. FUS 503512)
(See page 14)
Dip Switch Settings (SW2)
(See Page 14)
Voltage Selector (SW3)
SW3 - Position 1 = 115 Volts
SW3 - Position 2 = 230 Volts
(Shown As 115 Volt Selected)
Thermistor Fuses (FS2 & FS3)
63 Milliamp, 250 Volt
(Part No. FUS503511)
Rotary Mode Switch (SW4)
(See Page 13)
Thermistor & On Line Dip Switch Settings
(See Page 15)
Page 12
