Open Date SPRINT MAJOR Operator Instructions Manual page 11

Sprint Major - Digi60
Sprint Major Connection Details
SPRINT MAJOR
PRINTER
AIR SOLENOID
VALVE ASSEMBLY
(pages 10, 16, 18)
PRINT
TRIGGER
SIGNAL
(page 16,17)
Digi-60
CONTROLLER
AC MAINS SUPPLY
©2023 Open Date Equipment Limited All rights reserved.
REV A February 2023
6mm/8mm Black Nylon Tubing
6mm/8mm Red Nylon Tubing
PRINTER
CONNECTOR
(page 16,17)
PROTECTIVE EARTH
Retaining screws must
be tightened to maintain
earth continuity between
printer and power supply.
(page 4 section 10)
AIR SUPPLY. 6mm/8mm DIA
NYLON TUBING.
4 - 7 BAR (60 - 100 Psi)
CLEAN, DRY AIR.
Page 11
