User Manual
No. Name
2 Hanger
3 LED pannel
Electrical
4
connection area
Dimensions
The following figure shows the dimensions of the inverter.
Inverter Model
SH8.0RS / SH10RS
2.3 Symbols on the Product
Symbol
Description
To hang the inverter on the wall-mounting bracket.
The LED screen indicates the running information and the
LED indicator indicates the current working state of the
inverter.
PV terminals, battery terminal, AC terminal, additional
grounding terminal and communication terminals.
figure 2-2 Dimensions of the Inverter
W (mm)
605
Explanation
DC parameters on the PV side.
Parameters on the battery side.
Parameters on the AC on-grid side.
Parameters on the AC backup side.
Regulatory compliance mark.
2 Product Description
H (mm) D (mm)
435 181
11
