e Indicates accessed band's tuning step in-
crements after pushing [FUNC]; use the
then tuning dial to change the tuning steps.
(p. 18)
- Tuning steps can be separately selected for
FM and SSB/CW.
FM : 0.1, 5, 10, 12.5, 20, 25, 100 kHz
SSB/CW: 1, 10, 50, 100 Hz
@ SPEECH/SET MODE SWITCH [SPCH>SET]
eAnnounces the accessed band's fre-
quency, mode, etc. when an optional
UT-102 VOICE SYNTHESIZER UNIT is in-
a stalled. (pgs. 46, 52)
eEnters set mode when pushed for 2 sec.
Pushand Push the following switch to access set
noe mode contents. (p. 43)
-The [M/S], [CHECK], [TONE], [FUNC],
[SUB], [FM], [SSB/CW], [RIT], [kHz/MHz],
[SCAN], [ATT] and [PREAMP] switches have
set mode content(s).
@ SCAN SWITCH [SCANsSUBsS]
scan] = e Starts and stops the accessed band pro-
C8 grammed scan, memory scan or mode
select memory scan. (p. 38)
ica Starts and stops the sub band pro-
SCANEIEY grammed scan, memory scan or mode
CO select memory scan after pushing
[FUNC]. (p. 38)
CODO Cancels the tracking function when
Push in pushed; the tuning dial changes the sub
satellite mode A
band only, for Doppler shift compensa-
tion, in satellite mode. (p. 40)
scan gE
COO °Starts the optional tone scan when the
Push and tone squelch is in use and pushed for 2
neg sec. (p. 32)
- An optional UT-84 TONE SQUELCH UNIT İS re-
quired.
@ RF POWER CONTROL [RF PWR] (p. 25)
Adjusts the RF output power continuously.
-VHF FMCW 45-6W
SSB 35-6 W
-UHF FM/CW 406W
SSB 30-6 W
RF PWR
Decreases ¢ © \ Increases
PANEL DESCRIPTION 1
®© TUNING DIAL (p. 18)
Changes the displayed frequency, etc.
- While rotating the tuning dial in SSB/CW mode and in
1, 10 or 50 Hz tuning steps, the memory channel read-
out shows below the 10 Hz-digit. This returns to chan-
nel number indication 1 sec. after tuning.
Tuning rates (frequency change/rotation of tuning dial)
250 khz
@ BRAKE ADJUSTMENT SCREW
Adjusts the tuning dial tension.
@ MIC GAIN CONTROL [MIC] (p. 25)
Adjusts microphone input gain.
- For SSB mode, adjust the [MIC] control so the [TX] indi-
cator brightly illuminates (ALC activates) periodically
during normal voice transmission.
Recommeneded level for
an Icom microphone
Decreases { © i Increases
MIC
