Make call to extension
Play recorded audio
Dial Out Extension
Dial Out ID
Discovered Remote Relays
Product Type
IP Address
MAC Address
Serial Number
Name
Version
Operations Guide
Table 2-20. DSR Configuration Parameters (continued)
Description
When selected, the device will call an extension when the
remote (DSR) door sensor is activated. Use the 'Dial Out
Extension' field below to specify the extension the device will
call.
When selected, the device will call the Dial Out Extension and
play an audio file to the phone answering the SIP call
(corresponds to Door Ajar on the Audiofiles page) when the
remote (DSR) door sensor is activated.
Specify the extension the device will call when the remote
(DSR) door sensor is activated. Enter up to 64 alphanumeric
characters.
An additional Caller identification string added to outbound
calls. Enter up to 64 alphanumeric characters.
Use this button to test the remote relay.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of
some of the web page items. First click on the Toggle Help
button, and you will see a question mark (
some of the web page items. Move the mouse pointer to hover
over a question mark to see a short description of a specific
web page item.
Displays the product type of the remote relay.
Displays the IP address of the remote relay.
Displays the MAC address of the remote relay.
Displays the serial number of the remote relay.
Displays the name of the remote relay.
Displays the version of the remote relay.
Use this button to search for and find any remote relays that are
available on the network.
Use this button to view the settings of a remote relay that has
been "discovered" after pressing the Discover button.
Use this button to associate the remote relay with the device.
Only one relay may be associated with a device.
