Wren FI.PK.FIT.009 Fittings Manual page 2

WALL CABINET
PENINSULAR FITTING GUIDE
FI.PK.FIT.009 - Peninsular Frame
INSTALLATION SHOULD BE PERFORMED BY A COMPETENT PERSON ONLY.
Screws for fixing to walls are not provided as these vary depending on your wall
material and construction. Ensure appropriate fixings for wall constructions are used.
Step 1.
Measure and mark on the wall where the centre of the bottom of cabinet needs to be.
See customer specific kitchen plan for reference.
Step 2.
Mark location on the wall of the 2 x frame screw holes, see image below. Use the leg to support the end
of the frame. Secure the frame to the wall using 2 x appropriate fixings. Fixings not supplied.
Ensure the frame is level.
For Internal Use: FI.PK.FIT.009_50-WKIN00203_Peninsular_Unit_Guide_Rev5
THIS PRODUCT COULD BE DANGEROUS IF INCORRECTLY INSTALLED
BEFORE YOU START
