CHEST UNIT
Feature Open Chest & Storage Unit Fitting Guide
FEATURE CHEST 1 - FI.PK.BED.222.016
(K) x8
(L) x18
30mm
15mm
Screw
Screw
Screws and fixings for attaching to walls and chest tops are not provided as
For Internal Use: FI.PK.BED.222.016_WBIN00039_FeatureChest1_FittingGuide_Rev1
2x Corner Gusset Plate
these vary depending on materials, thickness and construction.
Ensure appropriate fixings are used.
Step1.
Place the unit on its side. Secure each of the legs in place with 2 x 15mm
screws (L) per leg.
Ensure legs are rotated as shown so the tab is supporting the end panel.
Attach bottom section of legs and set all legs to the same height.
Page 1
