ROBE UNIT
Under Robe Fitting Guide
UNDER ROBE 1 - FI.PK.BED.222.015
500 Width used for illustrative purposes only
Step 2.
Lift the unit upright. Once in situ level accordingly, using an 8mm hex key from inside the unit.
For Internal Use: FI.PK.BED.222.015_WBIN00033_UnderRobe1_Rev1
6 x 30mm Screw
Step 1.
Position top section of legs as shown. Ensure legs are rotated to provide support to the
end panels. Secure with 2 x 15mm screws per leg.
Attach bottom section of legs and set all legs to the same height.
400 - 500 Widths: 4 Legs
800 - 1000 Widths: 5 Legs
