FITTING GUIDE
VOID CORNER POST
I
I
D
Page 1
C
B
Sample cabinet shown
C
Step 1.
Place the Packer (C) flush with the front edge of the cabinet. Screw into any
side units using the 1
the rear of the hinge mounting plate, at the top and the bottom of both sides
of the unit.
Conceal screw head under hinge bracket where possible.
Repeat this step on the adjoining cabinet with packer (D), making sure to place
the panel on the correct side as shown above.
I
I
FI.PK.FIT.010 - VOID CORNER POST
(I) x8 1
" Screws
3/4
Panel A
Panel B
D
A
" screws (I) provided to secure the unit. Screw just to
3/4
For Internal Use: FI.PK.FIT.010_50-WKIN00005_Void_Cnr_Post_Rev2.indd
(H) x6 1
" Screws
1/4
Packer C/D (3
5/8
")
