Main Menu "Parameter Change" Functions List - Zapi EPS-AC0 SWs&ENC User Manual

11.4.4 Main menu "PARAMETER CHANGE" functions list

To enter the MAIN MENU it is just necessary to push the ENTER button from the
home display in the hand set.
1) Opening Zapi Menu
2) Press ENTER to go into the General Menu
3) The Display will show: PARAMETER CHANGE
4) Press ENTER to go into the Parameter
Change facility
5) The Display will show the first parameter
6) Press either ROLL UP and ROLL DOWN to
display the next parameter
7) The names of the Parameters appear on the
Display
8) When desired Parameter appear, it's possible
to change the Level by pressing either SET UP
or SET DOWN buttons.
9) The Display will show the new level
10) When you are satisfied with the result of the
changes you have made, press OUT
11) The Display asks: "ARE YOU SURE?"
12) Press ENTER to accept the changes, or press
OUT to discard them
13) The Display will show
AEMZP0EA - EPS-AC0 SWs&ENC - User Manual
Figure 11–7
EPSAC0 S ZP1.93
24V 50A 00000
' % '
' ' '
MAIN MENU
PARAMETER CHANGE
' % '
' ' '
SPEED LIMIT
LEVEL = 7
% ' '
% ' '
SENSITIVITY
LEVEL = 0
' ' %
' ' %
SENSITIVITY
LEVEL = 1
' ' '
' % '
ARE YOU SURE?
YES=ENTER NO=OUT
' ' '
' % '
MAIN MENU
PARAMETER CHANGE
Page - 67/95
