11.4.2 Config menu "ADJUSTMENTS" functions list

To enter the CONFIG MENU it is necessary to push in the same time the right side
top and left side top buttons. Then roll until the ADJUSTMENTS item appears on the
hand set display. Push the ENTER button (see the Figure 11-5 below).
1) Opening Zapi Menu
2) Press Top Left & Right Buttons to enter
CONFIG MENU
3) The Display will show: SET MODEL
4) Press ROLL UP button until ADJUSTMENTS
MENU appears
5) ADJUSTMENTS appears on the display
6) Press ENTER to go into the ADJUSTMENTS
MENU
7) The display will show:
8) Press ROLL UP or ROLL DOWN button until
the desired parameter is reached
9) The desired parameter appears
10) Press SET UP or SET DOWN button to modify
the adjustment
11) Press OUT
12) Press ENTER to confirm
13) Repeat the same from 5 to 12 points for the
other adjustments
Page - 60/95
Figure 11–5
AEMZP0EA - EPS-AC0 SWs&ENC - User Manual
EPSAC0
S ZP0.70
24V 50A 00000
% ' %
' ' '
CONFIG MENU
SET MODEL
% ' '
' ' '
CONFIG MENU
ADJUSTMENTS
' % '
' ' '
ADJUSTMENT #01
LEVEL= 0
% ' '
% ' '
SET SAT. FREQ.
100HZ
' ' %
' ' %
SET SAT. FREQ.
110HZ
' ' '
' % '
' % '
' ' '
