11.4.3 Config menu "SET MODEL" functions list

To enter the CONFIG MENU it is necessary to push in the same time the right side
top and left side top buttons. Then roll until the SET MODEL item appears on the
hand set display. Push the ENTER button (see the Figure 11-6 below).
1) Opening Zapi Menu
2) Press Top Left & Right Buttons to enter
CONFIG MENU
3) The Display will show: SET MODEL
4) Press ENTER to go into the SET MODEL
MENU
5) The display will show:
6) Press ROLL UP or ROLL DOWN button until
the desired parameter is reached
7) The desired parameter appears
8) Press SET UP or SET DOWN button to modify
the adjustment
9) Press OUT
10) Press ENTER to confirm
11) Repeat the same from 5 to 10 points for the
other adjustments
Page - 64/95
Figure 11–6
AEMZP0EA - EPS-AC0 SWs&ENC - User Manual
EPSAC0 S ZP0.70
24V 50A 00000
% ' %
' ' '
CONFIG MENU
SET MODEL
' % '
' ' '
SYSTEM CONFIG
LEVEL= 0
% ' '
% ' '
MODEL TYPE.
0
' ' %
' ' %
MODEL TYPE.
1
' ' '
' % '
' % '
' ' '
