11.4.1 Config menu "SET OPTIONS" functions list

To enter the CONFIG MENU it is necessary to push in the same time the right side
top and left side top buttons. Then roll until the SET OPTION item appears on the
hand set display. Push the ENTER button (see Figure 11-4).
Opening Zapi Display
Push ROLL UP + SET UP simultaneously to enter
CONFIG MENU
The Display will show : SET MODEL
Press ROLL UP or ROLL DOWN button until SET
OPTIONS menu appear
The Display will show : SET OPTIONS
Press ENTER to go in the SET OPTIONS MENU
The Display will show the first OPTION
Press SET UP or SET DOWN button in order to
modify the OPTION
The Display will show the new option
Press OUT to exit the menu
The Display will ask "ARE YOU SURE?"
Press ENTER for YES, or OUT for No
The Display will show : SET OPTIONS
Press OUT again. Display now will show the
opening Zapi menu
AEMZP0EA - EPS-AC0 SWs&ENC - User Manual
Figure 11–4
EPSAC0C2A ZP0.91
24V 50A 00000
% ' %
' ' '
CONFIG MENU
SET MODEL
% ' '
' ' '
CONFIG MENU
SET OPTIONS
' % '
' ' '
HOURCOUNTER
RUNNING
' ' %
' ' %
HOURCOUNTER
KEYON
' ' '
' % '
ARE YOU SURE?
YES=ENTER NO=OUT
' % ' ' ' '
' ' ' ' % '
CONFIG MENU
SET OPTIONS
' ' '
' % '
