Perlick CC24B-2 Installation & Operation Manual page 13

The anti-tip bracket and supporting hardware
is included with your unit. In the case of dual
installation, each individual unit must be
outfitted with the included anti-tip brackets.
For drawings of the anti-tip bracket installation
on integrated unit, see below. For drawings of
the anti-tip bracket installation on freestanding
units, see page 11.
WARNING
plumbing in the area which the screws
could penetrate.
Anti-Tip Bracket Installation for Built-In Applications
NOTE: Do not fasten anti-tip brackets to adjacent cabinetry until the cabinet has been leveled.
ANTI-TIP
BRACKETS
OUTER FRAME
ANTI-TIP BRACKETS
SIDE
POSITIONS FOR ANTI-TIP BRACKETS
Column Refrigeration Installation & Operation Manual
ANTI-TIP BRACKET
Verify there are no
electrical wires or
ANTI-TIP BRACKETS
INSTALLATION WITH OUTER FRAME
ANTI-TIP BRACKETS
INSTALLATION WITH CABINET WALLS
CAUTION
necessary protective devices or apparel
when installing or working with anchors.
Anchors are not recommended for use in
lightweight masonry material such as block
or brick, or for use in new concrete which
has not had sufficient time to cure. The use
of core drills is not recommended to drill
holes for anchors.
OUTER FRAME
ANTI-TIP
BRACKETS
13
Always wear safety
glasses and use other
OUTER FRAME
ANTI-TIP BRACKETS
INSTALLATION WITH OUTER FRAME
DOOR NOT SHOWN
DETAIL P
SCALE 1 : 6
OUTER FRAME
ANTI-TIP
BRACKETS
