- Page 1 CR24 & CR30 USE & CARE GUIDE PERLICK COLLECTION COLUMN REFRIGERATION To prevent appliance damage and injury, read these instructions thoroughly prior to operation. FORM NO. Z2497 REV. E-11/25/2020...
-
Page 2: Table Of Contents
PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE THANK YOU FOR CHOOSING PERLICK CONTENTS Congratulations on the purchase of your Perlick home Introduction appliance. Perlick’s innovative refrigeration product offering gives you the professional performance and functionality Touch-screen Controller Operation demanded in commercial kitchens and beyond. As a fifth- generation, family-owned company, our appliances reflect the 4 Refrigerator quality and craftmanship that we demand in our own homes. 8 Freezer Perlick has been designing, engineering and manufacturing 10 Wine Reserve award-winning products for the commercial food/beverage 13 Freezer Ambient Conditions service industry for over 100 years. Our award-winning products are trusted by bars, restaurants, hotels and large Stainless Steel/Surface Care venues around the world because a Perlick is built to last. Your Perlick home appliance is built with beauty and durability for 15 Adjusting the Wine Shelves a lifetime of use. This use and care guide will show you how to... -
Page 3: Introduction
PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE INTRODUCTION ABOUT THIS GUIDE SAFETY PRECAUTIONS This Use & Care Guide pertains to all Perlick Column Please take note of the following safety precautions prior to Refrigeration models. using your Perlick column refrigerator, freezer or wine reserve. ▪ Perlick column refrigeration is heavy. With a weight of up Keep this manual in a safe place for future reference. To better serve you, record your product’s information below, as we will to 550 lbs., it is imperative that the unit is properly installed request this information in the event you need assistance. and that the anti-tip brackets are fully engaged. ▪ Do not use or store flammable liquids (ie; gasoline) or vapors near the appliance. Model Number: ______________________________________ ▪ Take special care to keep fingers away from pinch points such as the hinges and gaps between the door and Serial Number: _______________________________________ cabinets. This can result in injury, especially to young Selling Dealer Name: __________________________________ children. - Page 4 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TOUCH-SCREEN CONTROL OPERATION - REFRIGERATOR MODELS REFRIGERATOR CONTROL OPERATION The following instructions are for the touch-screen control in Perlick column refrigerators. Control shown fully illuminated below for illustration purposes only. Using the Refrigerator Column Control Wake Button Upon door opening, the Wake button (1) outline will Temperature zone selection illuminate. Once activated, the temperature zone selection (2), temperature adjustment (7), temperature readout (8) and Deli temperature setting settings (15) menu icons will illuminate.
- Page 5 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TOUCH-SCREEN CONTROL OPERATION - REFRIGERATOR MODELS Main Compartment in the temperature readout (8). Double beep indicates that the The main compartment of the refrigerator features two minimum or maximum temperature full-width shelves and a split shelf that can be adjusted to has been reached. Temperature will fit tall items. Because this is a common zone that doesn’t flash twice to indicate new setting. store specific items, only the temperature adjustment (7) and temperature readout (8) will illuminate - no specialty temperature settings (Sp.) will appear. Middle Drawer Compartment The middle drawer compartment of the refrigerator features Compartment Factory Setting Temperature a full-width drawer designed for storing meat and seafood.
- Page 6 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TOUCH-SCREEN CONTROL OPERATION - REFRIGERATOR MODELS Bottom Drawer Compartment Column Theatre Lighting The bottom drawer compartment of the refrigerator features a Perlick column refrigerators feature an impressive amount of unique tip out bin design for storing fresh produce. When this lighting for clear viewing and display of goods. Main lighting zone is chosen, the fresh produce (carrot) temperature setting runs vertically down the walls and horizontally across the ceiling (6), temperature adjustment (7) and temperature readout (8) of the main compartment, deli drawer, meat/fish drawer and will illuminate. In addition to temperature-related icons, the tip-out produce bin. humidity control adjustment (10) icon will also illuminate. Changing from Fahrenheit to Celsius scale Compartment Factory Setting Temperature...
- Page 7 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TOUCH-SCREEN CONTROL OPERATION - REFRIGERATOR MODELS Quick Cool (Shopping) Mode The main compartment of the refrigerator can be set to Quick Cool (shopping) mode to lower the temperature after loading a large quantity of product to quickly bring them to the preferred temperature. Press the settings menu (15) icon on the far right. This will illuminate a cluster of four icons as shown to the left. To activate Quick Cool (shopping) mode, press the Quick Cool (14) icon. This will activate the mode and the Quick Cool (14) will remain illuminated until the set point is achieved. Showroom Mode Select Showroom mode for units that are being used solely for display purposes. Showroom mode has the user interface fully functional along with the cabinet lights, however, no compressor, evaporator fans or condenser fans will operate. Press the settings menu (15) icon on the far right. This will illuminate a cluster of four icons as shown to the left. A 5 key combination*,...
- Page 8 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TOUCH-SCREEN CONTROL OPERATION - FREEZER MODELS FREEZER CONTROL OPERATION The following instructions are for the touch-screen control in Perlick column freezers (model CR24F). Control shown fully illuminated below for illustration purposes only. Using the Freezer Column Control Wake Button Upon door opening, the Wake button (1) outline will illuminate. Temperature adjustment (up and down in Once activated, temperature adjustment (2), temperature 1°...
- Page 9 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TOUCH-SCREEN CONTROL OPERATION - FREEZER MODELS Column Theatre Lighting Please note that, when in Sabbath mode, the Sabbath mode (7) icon Perlick column freezers feature an impressive amount of lighting will be the only icon that will be for clear viewing and display of goods. White LED lighting runs illuminated (continuously) until user vertically down the walls and horizontally across the ceiling of presses the Sabbath mode icon to main compartment. turn the mode off. To adjust the brightness of the Quick Cool (Shopping) Mode lighting when the door is opened, press the up and down arrows in the The main compartment of the freezer can be set to Quick Cool light intensity adjustment icon (4).
-
Page 10: Wine Reserve
PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TOUCH-SCREEN CONTROL OPERATION - WINE MODELS WINE RESERVE CONTROL OPERATION The following instructions are for the touch-screen control in Perlick column wine reserves (model CR24W and CR24D). Control shown fully illuminated below for illustration purposes only. Using the Wine Column Control Wake Button Upon door opening, the Wake button (1) outline will Temperature zone selection (Dual-zone models) illuminate. Once activated, the temperature zone selection (2), temperature adjustment (7), temperature readout (8) and White wine temperature setting settings (15) menu icons will illuminate. - Page 11 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TOUCH-SCREEN CONTROL OPERATION - WINE MODELS Storing White Wine To adjust the temperature up or down, press the temperature Perlick wine columns are preset with expert-recommended adjustment (6) arrows until desired temperature settings for white wine. To set a zone in dual zone temperature is reflected in the models to this preset, touch the temperature zone selection temperature readout (7). Double icon (2) to illuminate the zone you’d like to set to white wine beep indicates that minimum or temperature, then choose the white wine temperature setting maximum temperature has been icon (3) to set. For single zone models, simply choose the white...
- Page 12 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TOUCH-SCREEN CONTROL OPERATION - WINE MODELS Column Theatre Lighting Changing from Fahrenheit to Celsius scale Perlick column wine reserves feature an impressive amount The controller is factory set to Fahrenheit scale, but can easily of lighting for clear viewing and display of wine bottles. Door be changed to read Celsius in the settings menu. open white LED lighting runs vertically down the walls and Press the settings menu (15) icon horizontally across the ceiling of each compartment. Door on the far right. This will illuminate closed (display) lighting can be changed from white to blue a cluster of four icons as shown to (blue will only illuminate the side walls.) the left. To display temperatures in Celsius, press the Celsius readout icon Wine models are factory set to white (12). lighting. To adjust the brightness of the lighting when the door is opened,...
-
Page 13: Freezer Ambient Conditions
PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TOUCH-SCREEN CONTROL OPERATION - WINE FREEZER AMBIENT CONDITIONS Showroom Mode Ambient Conditions Select Showroom mode for units that are being used solely For units installed in areas with changing ambient conditions, for display purposes. Showroom mode has the user interface please take note of the table below. In extreme conditions that fully functional along with the cabinet lights, however, no exceed those listed below, condensation may start to form on compressor, evaporator fans or condenser fans will operate. the front face of the cabinet. Condensation will subside as conditions return to levels below Press the settings menu (15) icon those shown in the table. on the far right. This will illuminate a cluster of four icons as shown to the left. A 5 key combination*, Ambient (F°) - Page 14 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE SURFACE CARE AND CLEANING STAINLESS STEEL CARE AND CLEANING frequently to avoid build-up of hard, stubborn stains. Stainless Steel Exterior Door Cleaning Stainless steel is a “passive” metal because it contains other metals like Chromium, Nickel and Manganese that stablize the Keep exterior stainless steel surface pristine by wiping the atoms. Chromium provides an invisible film that covers the steel door with a damp microfiber cloth, followed by a dry polishing surface, acting as a shield agent against corrosion. As long as chamois. Always follow the grain direction when cleaning. the film is intact and not contaminated, the metal is passive and stainless. If the passive film of stainless steel has been broken, the surface can start to corrode or rust.
-
Page 15: Adjusting The Wine Shelves
PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE ADJUSTING THE WINE SHELVES WINE SHELVING Prior to making shelf adjustments, clear the shelf of product. Shelf must be empty prior to changing its position. TO REMOVE WINE SHELVES TO INSTALL WINE SHELVES perlick customer service (800)558-5592 | 15... - Page 16 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE INSTALLING FILTERS CARBON AIR FILTERS ETHYLENE FILTERS Carbon air filters should be placed in the holder in the Ethylene filters should be placed in the holder in top of the tip- perforated panel located in the top-rear of the cabinet (A). out produce bin (B). NOTE: When installing carbon air filter in wine units, the top 1. Remove the filter from the plastic bag before installing into rack will need to be removed to access the perforated panel.
-
Page 17: Troubleshooting
PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TROUBLESHOOTING If the unit appears to be malfunctioning, check the troubleshooting guide below to see if you can identify the cause and remedy for the issue and resolve it without a service call. Problem Cause Solution Press the settings menu icon ( ) to illuminate a cluster of four icons. A five key combination - F-C-F-C- Settings - will exit showroom mode as shown below: UI flashes Cabinet is in Showroom Mode Door has been open for more than 3 Door alarm is beeping Close the door minutes Light stays on when door is Follow directions above to turn off Door Closed with Door Closed with Light (Display) closed (wine units) Light (Display) mode. Determine what may be causing the door to not fully Door not closing correctly Light stays on when door is close closed (all units) - Page 18 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE TROUBLESHOOTING Make sure the door is closing properly. Check the door deal and replace if necessary Condensation forms inside Door is not closing and sealing properly the compartments If condensation persists, contact Perlick Technical Service at (844) 411-8050 Soft sounds from compressor, fan motor Normal operation and valves heard Noisy operation “Crackling” sounds during defrost Normal operation Home circuit breaker was tripped. Reset the circuit breaker Unit is not running No power going to the unit Ensure the unit is plugged in Ensure the unit is not in “Showroom” mode Below is a list of column troubleshoot codes. If the cause occurs, the corresponding code will flash on the PerlIQ™ touch- screen control. See the Solution column on the far right for the corrective action. Code Cause Solution P1, P2, P3, P4, P5, P6 Temperature or humidity sensor failure Call Perlick Technical Service at (844) 411-8050 High and Low temperature alarms may occur from...
-
Page 19: Warranty
PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE WARRANTY PERLICK CORPORATION Period. For upright refrigerators, the Extended Warranty Period is the portion of the twelve (12) year period commencing on RESIDENTIAL REFRIGERATION PRODUCTS LIMITED the date of purchase by the original retail purchaser that is not WARRANTY covered by the Basic Warranty Period. WARRANTY: For a floor display model sold six years or more after being put on the floor, there is no warranty and such product is sold on an Perlick Corporation (“Perlick”) warrants to the original retail “as is” basis. purchaser that during the Basic Warranty Period, Perlick’s products will be free from defects in material and workmanship, and during the Extended Warranty Period, the hermetically REMEDY: sealed refrigeration system contained in Perlick’s undercounter or upright refrigerators will be free from defects in material and Perlick will provide the parts and labor necessary to repair or workmanship. This system consists entirely of the compressor, replace (at Perlick’s option) any parts proven to be defective condenser, drier, connecting tubing, evaporator and hot gas in material or workmanship during the Basic Warranty Period. bypass valve. Perlick will provide the replacement parts, but not the labor, for any parts of the hermetically sealed refrigeration system proven to be defective in materials or workmanship during The Basic Warranty Period is as follows: the Extended Warranty Period. The cost of freight to ship... - Page 20 PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE Department at warrantyserv@perlick.com. In addition, you PERLICK’S SOLE LIABILITY AND YOUR EXCLUSIVE REMEDY can notify Perlick of a warranty claim by submitting the form on UNDER THIS WARRANTY ARE SET FORTH IN THE PARAGRAPH the Perlick website at www.perlick.com/residential/contact ENTITLED “REMEDY” SET FORTH ABOVE. and choosing ‘Service’ from the department list. PERLICK SHALL HAVE NO LIABILITY WHATSOEVER FOR ANY All service provided by Perlick under this Warranty must be INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARISING performed by Perlick’s authorized service representatives, FROM THE SALE, USE OR INSTALLATION OF THE PRODUCT OR unless otherwise specified by Perlick in writing. Service will be FROM ANY OTHER CAUSES WHATSOEVER, WHETHER BASED provided during normal business hours. ON WARRANTY (EXPRESS OR IMPLIED) OR OTHERWISE BASED ON CONTRACT, TORT OR ANY OTHER THEORY OF LIABILITY. This Warranty applies only to the original retail purchaser of the IN NO EVENT SHALL PERLICK’S LIABILITY WITH RESPECT TO A Perlick product, and may not be assigned or transferred. PRODUCT EXCEED THE PURCHASE PRICE OF THE PRODUCT. This Warranty does not apply to: Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or ▪ Damage to Products occurring during transportation. consequential damages, so the above limitations and exclusions ▪ Products that are used in a manner that is not normal may not apply to you. This Warranty gives you specific legal residential or light commercial use. rights, and you may also have other rights, which vary from ▪...
-
Page 21: Contact Us
PERLICK RESIDENTIAL COLUMN REFRIGERATION USE & CARE GUIDE CONTACT US For Replacement Parts For Product Information ▪ Use only genuine Perlick replacement parts and ▪ Contact your selling dealer accessories. Genuine Perlick parts and accessories are ▪ Inquire via the web at perlick.com/residential designed to work correctly with Perlick products and offer ▪ Call (800) 558-5592 for factory assistance on planning surperior service life. The use of non-Perlick parts can installation or product information damage the unit and may void the warranty. ▪ Write to Perlick Corporation, Residential Customer Service, ▪ Prior to contacting Perlick, check the identifiction plate (see 8300 W. Good Hope Rd., Milwaukee, WI 53223, USA page 2 for location) for the serial number on the cabinet ▪ Email us at residentialsales@perlick.com you are calling about. ▪ Visit perlick.com/residential/contact and live chat with Perlick Technical Service 7am-6pm Monday-Friday. Look for... - Page 22 Perlick Residential is a division of Perlick Corporation © 2020 Perlick Corporation 8300 West Good Hope Road, Milwaukee, WI 53223, USA perlick.com/residential • (800) 558-5592 FORM NO. Z2497 REV. E-11/25/2020...
