To calibrate:
1. Locate a measured mile or KPM where you can safely start and stop your vehicle.
By running the vehicle over this measured distance, the speedometer will learn the
number of pulses outputted by the speedometer sensor during a specific measured
distance. It will then use this acquired data to calibrate itself for accurate reading.
There is a small recall pushbutton in the center of the panel used to calibrate and read
all the data stored in the speedometer. After installing your speedometer according to
the wiring instructions, when the ignition is on it should immediately display the default
screen of 0 MPH if the vehicle is not moving.
NOTE: You will then need to drive your vehicle to the predetermined measured mile.
During this trip, the speedometer should read something other than 0 MPH. If it does not
change, return, and locate the problem before continuing. Otherwise, proceed with the
calibration.
2. Stop at the beginning of the measured mile with your vehicle running and in odometer
mode (NOT trip mode), press and hold the push-button until the odometer displays 'HI-
SP'. On its own, the gauge will then cycle through the recorded performance in the
following order: '0 – 60', '1/4', 'ODO', and 'CAL'.
3. While 'CAL' is displayed, quickly tap the push-button once. This will put the
speedometer in Program Mode. If you did not tap while 'CAL' is displayed, the pulses
per mile will be displayed on the odometer and the display will go back to MPH mode.
Otherwise, you will now see 'CAL' displayed along with the number '0'. This indicates
that the microprocessor is now ready for calibration.
4. When you are ready, begin driving on the metered mile. You will notice that the
reading will start counting. The odometer will begin to display the incoming pulse
count. Drive the vehicle through the measured mile (speed is not important, only the
distance traveled).
5. At the end of the mile, stop and press the push-button again. The odometer will now
display the new number of speedometer pulses that were registered over the distance.
The odometer will continue to display the pulse reading for a few seconds. Once it
reverts to the default mode, you have successfully calibrated your speedometer.
