Made in America
Thank you for purchasing this instrument set from Intellitronix. We value our customers!
* Always disconnect the battery before attempting any electrical work on your vehicle.*
Parts included in this package -
◊ Fuel Level Gauge
◊ Oil Pressure Gauge and sending unit
◊ Speedometer and sending unit
◊ Tachometer
◊ Voltmeter
◊ Water Temperature Gauge and sending unit
GENERAL WIRING INSTRUCTIONS
Note: Automotive circuit connectors are the preferred method of connecting wires. However, you may
solder if you prefer.
(Each gauge has the three basic wires: black, red and purple. Additional wiring for each
gauge is with the individual gauge instructions: yellow connects to the fuel sending unit in
the tank; orange to the oil pressure sender; white to speedometer; green to tachometer and
blue to water temperature.)
Ground - Black Connect directly to an engine ground such as the engine block. For the most
accurate readings, connect to the same ground as the sending unit.
Power - Red Connect to a switched +12V source such as the ignition switch.
Note: The device will NOT function properly without a steady +12V source. For best results use a multimeter to
test the power source.
Dimmer – Purple Connect to the parking lights to dim the LEDs 50% when the headlights are on.
However, do not connect to the headlight rheostat control wire; as the dimming feature will not
work properly. Otherwise, connect to ground for permanent 100% brightness.
Fuel Level Gauge
Model
Ford/Chrysler
GM
VDO
Universal
1 - B-9999
INSTALLATION GUIDE
Bargraph Multi-Gauge Set with sending units
Part Number: B-9999
For ALL Instruments in this set:
Resistance
73 to 10 OHM
0 to 90 OHM
10 to 180 OHM
240 to 33 OHM
Intellitronix
Lifetime Guarantee
Wire(s) to cut
NONE
Blue
Blue & Orange
Orange
(rev.07/2018)
www.intellitronix.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Intellitronix B-9999
Summary of Contents for Intellitronix B-9999
- Page 1 Made in America Lifetime Guarantee Thank you for purchasing this instrument set from Intellitronix. We value our customers! INSTALLATION GUIDE Bargraph Multi-Gauge Set with sending units Part Number: B-9999 * Always disconnect the battery before attempting any electrical work on your vehicle.* Parts included in this package - ◊...
- Page 2 It will resemble a small plug emerging from the transmission with an electrical cord or cable connected to it. Connect the wires as above, plus the white wire to the LED Speedometer wire. 2 - B-9999 Intellitronix www.intellitronix.com (rev.07/2018)
- Page 3 CALIBRATION Note: If using the Intellitronix GPS Sending Unit (not included), the speedometer does not need to be calibrated. The speedometer leaves the factory with a pre-set industry standard setting of 8,000 pulses per mile.
- Page 4 Follow these steps to record and recall Performance Data (high speed, ¼mile ET, and 0-60 time): Before each run, your car must be at a complete stop at the starting position. Press and hold the push-button as it cycles through the performance data. At the end, the odometer will 4 - B-9999 Intellitronix www.intellitronix.com...
- Page 5 If your vehicle has a GM HEI ignition, connect to the terminal marked ‘TACH’, or, on some systems, a single white wire with a spade terminal. If your vehicle has an after-market ignition – some systems will connect to the TACH output terminal. 5 - B-9999 Intellitronix www.intellitronix.com (rev.07/2018)
- Page 6 Press the button on the lower right corner of the gauge to display the recall value. Press and hold for several seconds to clear memory and reset the recall to ‘0’. Voltmeter The Intellitronix Bargraph voltmeter is compatible with any vehicle. The microprocessor provides accurate readings from 12V to 16V.
- Page 7 Made in America Lifetime Guarantee Technical Support Monday – Friday 9am to 5 pm EST (440) 210-7646 support@intellitronix.com This product carries a limited Lifetime Warranty. This warranty is limited to replacement or repair of the unit at the discretion of Intellitronix.
