Intellitronix BG10002 Installation Manual page 6

Recording and Viewing Performance Data
Follow these steps to record and recall Performance Data (high speed, ¼mile ET, and 0-60 time):
Before each run, your car must be at a complete stop at the starting position. Press and hold
1.
the pushbutton as it cycles through the performance data. At the end, the odometer will re-
set and all performance data will be cleared. This will not affect your stored calibration
value or the odometer reading.
Press the push-button until 'HI-SP' is displayed. The gauge will automatically cycle through
2.
the performance data.
Start the run, pass, session, etc., as mentioned above.
3.
When finished, repeat Step 2 to view the data gathered from the run. While stopped, you
4.
can view this data as often as you wish. However, once it finishes scrolling one time, the
memory is ready to record new data and will begin recording again once the vehicle starts
to move. The highest speed measured over multiple runs will be retained in memory.
SPEEDOMETER CALIBRATION PROCEDURE
Your Intellitronix dash panel is equipped with our Digital Performance Speedometer which has
factory settings that are pre-set with the industry standard setting of 8,000 pulses per mile to
match your vehicles factory settings. This electronic speedometer displays speed and includes
an odometer, trip meter, high speed recall, 0-60 time, and quarter-mile elapsed time. It can be
calibrated with the push-button to adjust the speedometer when you have
wheel sizes, and gear ratios.
The single push-button is used by a quick tap to toggle between odometer and trip meter. The
microprocessor distinguishes between a quick tap and a press and hold which will reset the trip
meter in trip mode or display performance data in odometer mode.
CALIBRATION
The Digital Performance Speedometer leaves the factory with a factory pre-set industry standard
setting of 8,000 pulses per mile. You should not have to recalibrate your speedometer unless
you have changed the original tire size or the rear end gear ratio.
Also, if using the Intellitronix GPS Sending Unit, (S9021 – not included) the speedometer does
not need to be calibrated.
NOTE: DO NOT attempt to recalibrate your speedometer until after it is working properly,
and you have determined that the speed is consistently incorrect. The calibration procedure
will NOT correct a faulty installation or improper wiring.
WARNING: If, while in 'CAL' mode, you do not move the vehicle but press the button again,
the microprocessor will NOT have received any data and the unit will display 'Err' and will
revert to the factory settings. At a minimum, drive some distance and return to the start if
necessary. If you miss stopping the display at 'CAL', simply repeat the steps.
6 BG10002 Intellitronix Rev 01312022
Different sizes,
