EMI PERFORMANCE

The SWn pin provides access to the midpoint of the power
MOSFETs in LTM4681's power stages.
Connecting an optional series RC network from SWn to
GND can dampen high frequency (~30MHz+) switch node
ringing caused by parasitic inductances and capacitances
in the switched-current paths. The RC network is called a
snubber circuit because it dampens (or "snubs") the reso-
nance of the parasitics, at the expense of higher power
loss. To use a snubber, choose first how much power to
allocate to the task and how much PCB real estate is avail-
able to implement the snubber. For example, if PCB space
allows a low inductance 0.5W resistor to be used then the
capacitor in the snubber network (CSW) is computed by:
P
SNUB
C
=
SW
2
V • f
IN n (MAX)
SW
where V is the maximum input voltage that the
INn(MAX)
input to the power stage (V
and f is the DC/DC converter's switching frequency
SW
of operation. C should be NPO, C0G or X7R-type (or
SW
better) material.
The snubber resistor (R
SW
5nH
R =
SW
C
SW
The snubber resistor should be low ESL and capable of
withstanding the pulsed currents present in snubber cir-
cuits. A value between 0.7Ω and 4.2Ω is normal.
A 2.2nF snubber capacitor is a good value to start with in
series with the snubber resistor to ground. The no load
input quiescent current can be monitored while selecting
different RC series snubber components to get a increased
power loss versus switch node ringing attenuation.
78
) will see in the application,
INn
) value is then given by:
For more information

SAFETY CONSIDERATIONS

The LTM4681 modules do not provide galvanic isolation
from V to V . There is no internal fuse. If required,
IN OUT
a slow blow fuse with a rating twice the maximum input
current needs to be provided to protect each unit from
catastrophic failure.
The fuse or circuit breaker should be selected to limit the
current to the regulator during overvoltage in case of an
internal top MOSFET fault. If the internal top MOSFET
fails, then turning it off will not resolve the overvoltage,
thus the internal bottom MOSFET will turn on indefinitely
trying to protect the load. Under this fault condition, the
input voltage will source very large currents to ground
through the failed internal top MOSFET and enabled
internal bottom MOSFET. This can cause excessive heat
and board damage depending on how much power the
input voltage can deliver to this system. A fuse or circuit
breaker can be used as a secondary fault protector in
this situation. The device does support over current and
overtemperature protection.

LAYOUT CHECKLIST/EXAMPLE

The high integration of LTM4681 makes the PCB board
layout very simple and easy. However, to optimize its
electrical and thermal performance, some layout consid-
erations are still necessary.
Use large PCB copper areas for high current paths,
n
including V , GND and V
INn
the PCB conduction loss and thermal stress.
Place high frequency ceramic input and output capac-
n
itors next to the V , GND and V
INn
high frequency noise.
Place a dedicated power ground layer underneath the
n
module.
To minimize the via conduction loss and reduce mod-
n
ule thermal stress, use multiple vias for interconnec-
tion between top layer and other power layers.
