LTM4681
PMBus COMMAND DETAILS
EVENT n-1
(data measured before fault was detected)
READ_VOUT (PAGE 0)
READ_VOUT (PAGE 1)
READ_IOUT (PAGE 0)
READ_IOUT (PAGE 1)
READ_VIN
READ_IIN
STATUS_VOUT (PAGE 0)
STATUS_VOUT (PAGE 1)
STATUS_WORD (PAGE 0)
STATUS_WORD (PAGE 1)
STATUS_MFR_SPECIFIC (PAGE 0)
STATUS_MFR_SPECIFIC (PAGE 1)
EVENT n-5
(Oldest Recorded Data)
READ_VOUT (PAGE 0)
READ_VOUT (PAGE 1)
READ_IOUT (PAGE 0)
READ_IOUT (PAGE 1)
READ_VIN
READ_IIN
STATUS_VOUT (PAGE 0)
STATUS_VOUT (PAGE 1)
STATUS_WORD (PAGE 0)
STATUS_WORD (PAGE 1)
STATUS_MFR_SPECIFIC (PAGE 0)
STATUS_MFR_SPECIFIC (PAGE 1)
128
[15:8] LIN 16 47
[7:0] LIN 16 48
[15:8] LIN 16 49
[7:0] LIN 16 50
[15:8] LIN 11 51
[7:0] LIN 11 52
[15:8] LIN 11 53
[7:0] LIN 11 54
[15:8] LIN 11 55
[7:0] LIN 11 56
[15:8] LIN 11 57
[7:0] LIN 11 58
BYTE 59
BYTE 60
[15:8] WORD 61
[7:0] WORD 62
[15:8] WORD 63
[7:0] WORD 64
BYTE 65
BYTE 66
[15:8] LIN 16 127
[7:0] LIN 16 128
[15:8] LIN 16 129
[7:0] LIN 16 130
[15:8] LIN 11 131
[7:0] LIN 11 132
[15:8] LIN 11 133
[7:0] LIN 11 134
[15:8] LIN 11 135
[7:0] LIN 11 136
[15:8] LIN 11 137
[7:0] LIN 11 138
BYTE 139
BYTE 140
[15:8] WORD 141
[7:0] WORD 142
[15:8] WORD 143
[7:0] WORD 144
BYTE 145
BYTE 146
