LTM4681

PACKAGE PHOTOS

DESIGN RESOURCES

SUBJECT
µModule Design and Manufacturing Resources
µModule Regulator Products Search
Digital Power System Management

RELATED PARTS

PART NUMBER DESCRIPTION
LTM4675 Dual 9A or Single 18A Step-Down μModule Regulator with
Digital Power System Management
LTM4686/ Ultrathin Dual 10A or Single 20A μModule Regulator with
LTM4686-1 Digital Power System Management
LTM4676A Dual 13A or Single 26A Step-Down μModule Regulator with
Digital Power System Management
LTM4677 Dual 18A or Single 36A Step-Down μModule Regulator with
Digital Power System Management
LTM4678 Dual 25A or Single 50A μModule Regulator with Digital
Power System Management
LTM4664 54 VIN, Dual 25A or Single 50A μModule Regulator with
Digital Power System Management
LTM4680 Dual 30A or Single 60A μModule Regulator with Digital
Power System Management
LTM4700 Dual 50A or Single 100A μModule Regulator with Digital
Power System Management
134
Part marking is either ink mark or laser mark
DESCRIPTION
Design:
• Selector Guides
• Demo Boards and Gerber Files
• Free Simulation Tools
1. Sort table of products by parameters and download the result as a spread sheet.
2. Search using the Quick Power Search parametric table.
Analog Devices' family of digital power supply management ICs are highly integrated solutions that
offer essential functions, including power supply monitoring, supervision, margining and sequencing,
and feature EEPROM for storing user configurations and fault logging.
For more information
Manufacturing:
• Quick Start Guide
• PCB Design, Assembly and Manufacturing Guidelines
• Package and Board Level Reliability
COMMENTS
4.5V ≤ V ≤ 17V, 0.5V ≤ V ≤ 5.5V,
IN OUT
11.9mm × 16mm × 3.51mm BGA
4.5V ≤ V ≤ 17V, 0.5V ≤ V ≤ 3.6V (LTM4686),
IN OUT
2.375V ≤ V ≤ 17V (LTM4686-1) 11.9mm × 16mm × 1.82mm LGA
IN
4.5V ≤ V ≤ 26.5V, 0.5V ≤ V
IN OUT
16mm × 16mm × 5.01mm BGA
4.5V ≤ V ≤ 16V, 0.5V ≤ V ≤ 1.8V, 16mm × 16mm × 5.01mm BGA
IN OUT
4.5V ≤ V ≤ 16V, 0.5V ≤ V ≤ 3.4V, 16mm × 16mm × 5.86mm BGA
IN OUT
30V ≤ V ≤ 58V, 0.5V ≤ V ≤ 1.5V, 16mm × 16mm × 7.72mm BGA
IN OUT
4.5V ≤ V ≤ 16V, 0.5V ≤ V ≤ 3.3V, 16mm × 16mm × 7.82mm BGA
IN OUT
4.5V ≤ V ≤ 16V, 0.5V ≤ V ≤ 1.8V, 15mm × 22mm × 7.87mm BGA
IN OUT
www.analog.com
≤ 5.5V,
www.analog.com
 ANALOG DEVICES, INC. 2021-2022
Rev. A
04/22
