Parameters
Fast feed speed (mm/s)
Fast feed acc (mm/s²)
Corner spd (mm/s)*
Corner acc (mm/s²)
Cutting acc (mm/s²)
Fast feed delay (ms)*
* If your engraving design has a lot of serrated or zigzag patterns, set the parameter at a value that best suits your
design. Practice on scrap materials first.
* When set to zero, the laser head doesn't rest after traveling without beaming. When set to a certain value, the
laser head slows down upon the completion of traveling without beaming and rest for the set milliseconds.
Parameters
Cut jerk (0–200%)
Fast feed jerk (0–200%)
Corner jerk (0–200%)
X Backlash (mm)
Y Backlash (mm)
Options Functions/Meanings
Numerical Sets the speed of the laser head when not firing laser beams.
Numerical Sets the acceleration of the laser head when not firing laser beams.
Numerical Sets the speed of the laser head when making sharp turns.
Numerical Sets the acceleration of laser head when making sharp turns.
Numerical
Sets the acceleration of the beaming laser head.
Numerical
Sets the time the laser head rests for after travelling without beaming.
Options Functions/Meanings
Numerical
Sets the speed of the laser head when beaming in percentages.
Sets the time the laser head rests for after travelling without
Numerical
beaming in percentages.
Sets the speed of the laser head when making sharp turns in
Numerical
percentages.
Numerical
Does not need adjusting.
Numerical
Does not need adjusting.
59
