USB Files
The system is compatible with FAT32 and FAT16 USB file formats. For best results, however, store your files
under the root directory of the USB flash drive so that the system can recognize them quicker and easier.
By default, the system dissects a file name exceeding 8 characters and shows it in more than one word. Also, the
system cannot recognize file whose names consist of characters other than English and Arabic numbers. All files
exported from the system to a flash drive are stored under the root directory of such storage gadget.
1. Tap "File" (if you haven't done this), and the file management menu pops up.
2. Tap "Udisk" to switch the memory route to the USB flash drive that's connected.
The 4 icons in the middle are for managing the USB files.
Copy: Copies the selected file from the flash drive to the system memory.
Del: Deletes the selected file.
Board: Upgrades mainboard program through the USB flash drive
Hmi: Upgrades the control panel program through the USB flash drive

5.4 Setting Speed Levels

1. Tap "Speed" in Parameter Display Area from the home menu,
and the following menu shows up.
When the system is idle, the speed parameters controls the
manual high speed and manual low speed. That is, the speed
range that the laser head can be manually moved to reach, which
is convenient for debugging and calibrating.
When the system is running or paused, those speed parameters
control the processing speed of the laser head.
2. Tap the parameter box to show the numeric keyboard as shown.
3. Set the value to that you desire.
4. Tap OK to confirm the modification and exit the current menu or
tap ESC to cancel the modification and exit the current menu.
