1 Overview

1.1

General

1.1.1

Introduction

The Mercury+ XU6 SoC module combines the Xilinx Zynq® UltraScale+ MPSoC ﴾Multiprocessor System‐
on‐Chip﴿ device with DDR4, QSPI, and eMMC memories, as well as PCIe, USB 2.0/3.0, and Gigabit Ethernet
interfaces. This module forms a complete and powerful embedded processing system, available in ex‐
tended and industrial temperature ranges.
The use of the Mercury+ XU6 SoC module, in contrast to building a custom MPSoC hardware, signif‐
icantly reduces development effort and redesign risk and improves time‐to‐market for the embedded
system.
Together with Mercury+ base boards, the Mercury+ XU6 SoC module allows the user to quickly build a
system prototype and start with application development.
The Enclustra Build Environment [16] is available for the Mercury+ XU6 SoC module. This build system
allows the user to quickly set up and run Linux on any Enclustra SoC module. It allows the user to choose
the desired target and download all the required binaries, such as bitstream and FSBL ﴾First Stage Boot
Loader﴿. It downloads and compiles all required software, such as U‐Boot, Linux, and BusyBox based root
file system.
1.1.2

Warranty

Refer to the General Business Conditions, available on the Enclustra website [1].
Tip
The warranty of Enclustra modules is void if the FPGA's one‐time programmable eFuses are blown. This
operation is irreversible. Enclustra cannot test the module in case of a product return.
NOTICE
Data loss or unusable product
The fuses of the FPGA can be blown to activate the user‐defined Advanced En‐
cryption Standard ﴾AES﴿. After blowing the fuses, only content encrypted using a
specific key can be loaded on the FPGA. Your key is unique and cannot be retrieved
in case of loss.
1.1.3

RoHS

The Mercury+ XU6 SoC module is designed and produced according to the Restriction of Hazardous
Substances ﴾RoHS﴿ Directive ﴾2011/65/EC﴿.
1.1.4

Disposal and WEEE

The Mercury+ XU6 SoC module must be properly disposed of at the end of its life.
The Waste Electrical and Electronic Equipment ﴾WEEE﴿ Directive ﴾2002/96/EC﴿ is not applicable for the
Mercury+ XU6 SoC module.
D‐0000‐464‐001
Keep your key in a secure location.
