3. Product Specific Precautions 3

Precautions 3

Maintenance Parts

Caution
SMC specified parts should be used for maintenance service.
Refer to Chapter 5, "Construction and Dimensions" (P. 11) for the part indication numbers.
Bonnet assembly/Part indication number (1)
Temperature
specifications
General use
High temperature
Temperature
specifications
General use
High temperature
Note 1) Add the seal material symbol shown on page 8 at the suffix of the model number. This is not
necessary for the standard seal material valve seal 1 and 2 (FKM: Compound No. 1349-80).
e.g.) XLA16A-30-1-2-XN1
Note 2) The magnet for auto switch is not provided. When the magnet for auto switch is necessary, add "-
M9//" at the suffix of the part number. (There is no magnet for auto switch for high temperature.)
e.g.) XLA16-30-1-2M9//
Note 3) Auto switch is not attached. When the auto switch is necessary as a set, add the symbols of the
auto switch at the suffix of the part number.
e.g.) XLA16A-30-1-2M9NA-XN1
Note 4) Bonnet assembly contains the valve seal 1, valve seal 2, bellows assembly, and nut assembly.
It does not contain external seal. Oerder separately if it is required.
External seal, Valve seal 1, Valve seal 2
Description
Material
Part indication No.
External seal
(4)
Valve seal 1
(2)
Valve seal 2
(3)
Description
Material
Part indication No.
External seal
(4)
Valve seal 1
(2)
Valve seal 2
(3)
Note 1) Add the seal material symbol shown on page 8 at the end of the model number (in place of ).
This is not necessary for the standard seal material (FKM: Compound No. 1349-80).
e.g.) AS568-025-XN1
Be sure to read before handling
Indicator
16
Without
XLA16-30-1-2
With XLA16A-30-1-2
Without XLA16-30-1H-2
With XLA16A-30-1H-2
Indicator
63
Without
XLA63-30-1-2
With XLA63A-30-1-2
Without XLA63-30-1H-2
With XLA63A-30-1H-2
Valve size
16
Standard AS568-025V
Special
AS568-025
Standard B2401-V15V
Special
B2401-V15
Standard B2401-P4V
Special
B2401-P4
Valve size
63
Standard AS568-043V
Special
AS568-043
Standard AS568-233V
Special
AS568-233
Standard B2401-P8V
Special
B2401-P8
Valve size
25
XLA25-30-1-2
XLA25A-30-1-2
XLA25-30-1H-2
XLA25A-30-1H-2
Valve size
80
XLA80-30-1-2
XLA80A-30-1-2
XLA80-30-1H-2
XLA80A-30-1H-2
Valve size
25
AS568-030V
AS568-030
B2401-V24V
B2401-V24
B2401-P5V
B2401-P5
Valve size
80
AS568-045V
AS568-045
B2401-V85V
B2401-V85
B2401-P10V
B2401-P10
- 7 -
40
XLA40-30-1-2 XLA50-30-1-2
XLA40A-30-1-2 XLA50A-30-1-2
XLA40-30-1H-2 XLA50-30-1H-2
XLA40A-30-1H-2 XLA50A-30-1H-2
40
AS568-035V AS568-039V
AS568-035 AS568-039
B2401-P42V AS568-227V
B2401-P42 AS568-227
B2401-P6V B2401-P8V
B2401-P6 B2401-P8
XL-OMS0001-D
