- Page 1 Doc. no.XL-OMV0017-A PRODUCT NAME High Vacuum L Type Valve MODEL / Series / Product Number XLF-2 Series...
-
Page 2: Table Of Contents
Contents Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1. Product Specific Precautions 1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - (Piping, Air Supply) 2. -
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. - Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
-
Page 5: Product Specific Precautions 1
1. Product Specific Precautions 1 Precautions 1 Be sure to read before handling. Piping Caution 1. Refer to the Fittings and Tubing Precautions on the SMC website for handling One-touch fittings. 2. Before piping is connected, it should be thoroughly blown out with air (flushing) or washed to remove chips, cutting oil and other debris from inside the pipe. -
Page 6: Product Specific Precautions 2
2. Product Specific Precautions 2 Precautions 2 Be sure to read before handling. Design Warning ●All models 1. The body material is A6063, and other metal seal material is SUS304 and A2017. Refer to Chapter 5, “Construction and Dimensions” (P. 11) for details. Standard seal material in the vacuum section is FKM that can be changed to the other materials. - Page 7 ●High temperature type (temperature specification / H0 H4 H5) 1. In models with a heater (thermistor), take care not to damage the insulation components of the lead wires and connector section. 2. The set temperature for models with a heater should be established at normal ambient temperature without any drafts or heat insulation.
-
Page 8: Product Specific Precautions 3
3. Product Specific Precautions 3 Precautions 3 Be sure to read before handling Maintenance Parts Caution SMC specified parts should be used for maintenance service. Refer to Chapter 5, “Construction and Dimensions" (P. 11) for the part indication numbers. Bonnet assembly/Part indication number (1) Temperature Valve size Indicator... - Page 9 Nut assembly Valve size Description Part indication No. Nut assembly XL1A16-10-1 XL1A25-10-1 XL1A40-10-1 XL1A50-10-1 Valve size Description Part indication No. Nut assembly XL1A50-10-1 XL1A80-10-1 Suffix for seal materials Barrel FKM for Seal material EPDM Kalrez Chemraz Perfluoro PLASMA Combination No. 2101-80 4079 SS592...
-
Page 10: Specifications
4. Specifications 4-1. Valve specifications Model XLF-16-2 XLF-25-2 XLF-40-2 XLF-50-2 XLF-63-2 XLF-80-2 Flange (valve) size Actuating type Normally closed Fluid Vacuum of inert gas Operating temperature 5 to 60 (5 to 150 for high temperature type) Operating pressure Pa(abs) Atmospheric pressure to 1 x 10 Conductance l/s Note 1) 1.3 x 10... - Page 11 4-2. Heater specifications Item XLF-25-2 XLF-40-2 XLF-50-2 XLF-63-2 XLF-80-2 90 to 240 ACV Rated voltage of the heater Heater assembly number XL1A25-60S-1 XL1A25-60S-1 XL1A25-60S-2 XL1A25-60S-3 No. of heater assemblies 1 pc. 1 pc. 1 pc. 1 pc. Initial power / 100 VAC 200/40 200/50...
-
Page 12: Construction And Dimensions
5. Construction and Dimensions 5-1. Construction Auto switch (Optional) Bonnet assembly (Maintenance part) (Including 2, 3, 6, 7, 8, 9, 10, 11, 12 and 13) Indicator (Optional) Magnet (Optional) Pilot port Rod cover (Material: A2017) Cylinder External seal (Maintenance part) Heater (Optional) Shaft seal (Material: FKM) Scraper (Material: FKM) - Page 13 5-2.Dimensions G Unit: mm Model XLF-16-2 XLF-25-2 XLF-40-2 XLF-50-2 XLF-63-2 XLF-80-2 - 12 - XL-OMV0017-A...
-
Page 14: How To Order
6. How to oder X L F A ( - X A N1 A ) Part with changed seal material Symbol Changed part Flange size Ｓize None ②,③,④ ②,③ ④ ② ②,④ *See the Contruction and part page11 Flange type Seal material FKM（Standard) Applicable flange... -
Page 15: Period And Scope Of Warranty
7. Period and Scope of Warranty The warranty period is 3 million cycles for sizes 16, 25 and 40, 2 million cycles for size 50,63 and 80 (under SMC's endurance test conditions), 1 year in service or within 1.5 years after delivery, whichever comes first. -
Page 16: Parts Replacement Procedure
8. Parts Replacement Procedure 8-1. Precautions Be sure to adhere to the instructions given in “2. Precautions 2“, when disassembling the product for maintenance. Along with the precautions listed in Chapter 2, the user should comply with those listed below. Warning •... - Page 17 8-2. Disassembly Procedure Step 1 Removal of bonnet assembly Step 2 Removal of valve seal 1 Valve Bolt Valve seal 1 Bonnet assembly Pilot port Bolt size, Tool Valve Bolt size size wrench Bottom surface of the XLF-16 groove to discharge gas.
- Page 18 8-3. Assembly Procedure Step 1 Preparation Step 2 Reassembly of valve seal 2 Apply a spanner to the Note) width across the flats of For XLF-16/25, mount the washer in the Clean cloth the shaft to prevent it orientation that the groove of the washer from rotating.
- Page 19 Step 5 Remount of external seal Step 6 Reassembly of bonnet assembly (No.1) Valve seal 1 External seal Mounting part of the external seal Surface of the rod cover Bonnet assembly (External seal) Body Wipe off any dust from the surface of the external Wipe off any dust from the surfaces of the valve seal and the mounting surface of the external seal seal 1 and the rod cover.
- Page 20 8-4. Heater Replacement Procedure Step 1 Assembly of heater Heat transfer sheet Heater Heater Body Mounting screw Body Heater cover Mounting screw Heater cover Size 25 Size 40 or larger Put heat transfer sheet(Note1), heater, heater cover to backside of body. Tighten the mountiug screws to install heater assembly.
- Page 21 Revision history A RENEWAL 1st printing: 2017.12 Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved - 20 - XL-OMV0017-A...
