Be sure to read before handling.
Specifications
1. Valve specifications
Switching method
Fluid
Operating pressure range [MPa]
Withstand pressure [MPa]
Ambient temperature and fluid
temperature [°C]
Humidity range
(During operation/storage)
Manual operation
Pilot exhaust method
Flow characteristics
Response time [ms]
Maximum duty ratio [%]
Min. operating frequency
Max. operating frequency [Hz]
Lubrication
Impact resistance/vibration
2
(4)
resistance [m/s
]
Enclosure
(In accordance with IEC60529)
Mounting orientation
Operating environment
(5)
Weight [kg]
(6)
B
[cycle]
10D
Mission time
Note
(1) The soft start-up valve is of the air return method.
(2) As the withstand pressure refers to a pressure range that does
not cause breakage with danger, do not apply a pressure
exceeding the maximum operating pressure range.
Failure to follow this instruction may lead to a malfunction or air
leakage.
(3) This occurs when the duty ratio is 50% and no load is applied.
(4) Impact resistance
- The product must not malfunction in an impact test that uses a
drop tester.
- No malfunction when the test is performed once each in the
axial/vertical directions of main valve and armature in energized
and de-energized conditions.
- Vibration resistance 45 to 2000 Hz
No malfunctioning in a single scanning
- No malfunction when the test is performed in the axial/vertical
directions of main valve and armature in energized and de-
energized conditions (the valve is in the initial state).
(5) The weight indicates the weight without M12 connector cable.
Weight of M12 connector cable (for 2 pcs.) = 0.4 kg
(6) The B10D value is predicted based on the life test conducted in
the SMC's test conditions.
(7) Refer to Section 10.5 of "Specifications" for details.
(8) This product is a pilot type solenoid valve with large flow rate.
Note that if the operating pressure drops to 0.25 MPa or below
because of pressure drop caused by an insufficient air supply
capacity, the valve may not be appropriately switched.
(25A-)VPX400 Series
3 port solenoid valve /

Specific Product Precautions 1

N.C.
(1)
(Spring return
)
Air
0.25 ~ 1.0
(2)
1.5
0 ~ 50
(No freezing)
35 ~ 85% RH
(No condensation)
None
Individual exhaust
Refer to the Section 2 of
"Specifications."
Refer to the Section 10.2 of
"Specifications."
100
1 time/7 days
(3)
1
No
150/30
IP40 (pressure gauge type:
E1/E2/E3/E4)
IP65 (pressure gauge type:
Nil/G/M/E)
Free
Indoors
A3 (AC30 connection size):
1.71
A4 (AC40 connection size):
1.71
A6 (AC60 connection size):
1.81
1,083,893
Maximum 20 years
or when the number of
cycles = B
whichever
10D,
(7)
occurs first.
(9) For the specifications of and precautions on various pressure
gauges (G/M/E/E1/E2/E3/E4), refer to the catalog for this series
or the operation manual. For other matters, refer to the catalog
and operation manual for the series shown in the table below.
Pressure gauge symbol
Series
2. Flow Characteristics
Series
Flow path
1 ⇒ 2
VPX406-A3
2 ⇒ 3
1 ⇒ 2
VPX406-A4
2 ⇒ 3
1 ⇒ 2
VPX406-A6
2 ⇒ 3
3. Solenoid specifications (SOL.)
Coil rated voltage
Electrical wiring
Allowable voltage fluctuation
Power consumption [W]
(Solenoid power consumption x
2 pcs.)
Surge voltage suppressor
LED
4. Failure detection specifications (SEN.)
Pressure
Sensor E
sensor
Sensor 2
Rated voltage [VDC]
Electrical wiring
Allowable voltage fluctuation
Power consumption [W]
(pressure sensor power
consumption × 2 pcs.)
Output type
Output mode
Maximum load current [mA]
Internal voltage drop [V]
SEN./PWR.
LED
ERR.
Note
(1) Refer to Section 10 "Safety system" of "Specifications" for the
details of the pressure sensors.
5. Digital pressure switch specifications (pressure gauge
type: E1/E2/E3/E4)
Display/lowest configurable
increment [MPa]
Rated voltage [VDC]
Allowable voltage fluctuation
Output type
Repeatability
Display accuracy
Electrical wiring
Note
(1) Refer to the ISE35 series catalog for the specifications of the
digital pressure switches and others. Refer to the specific
product precautions on ISE35 Series for how to handle them.
- 8 -
G/M
E
E1/E2/E3/E4
G46
AR-D
ISE35
(/ s・bar) ]
3
C[dm
16.2
0.40
25.0
0.20
20.0
0.30
31.0
0.15
22.6
0.25
35.8
0.10
DC[VDC]
24
M12 connector
-8% to +10% of
the rated voltage
At time of startup
0.45 x 2 pcs.
At time of holding
0.2 x 2 pcs.
Diode
SOL.1/SOL.2
LED (Green)
For detection of inconsistency
(1)
with main valve
For detection of 2-port output
24
M12 connector
±10% of rated voltage, and
power supply ripple of 10% or
less
0.3 x 2 pcs.
PNP open collector output
Hysteresis mode
80
1 or less (load current: 80 mA)
LED (green)
LED (red)
0.01
24
±10% of rated voltage, and power
supply ripple of 10% or less
NPN or PNP
Open collector output
±1% F.S.
±1% F.S. ±1 digit
(At 25°C±3°C)
M12 connector
No. DOC1092179
