Step 3: Unlocking the Scanner

1. Remove the yellow sticker "Unlock Scanner" from your scanner.
2. With the scanner power off, tilt the back right corner of the scanner to see
3. Push the locking switch to the position as indicated in the graphic, with the
NOTE: To lock the scanner (for shipping and other reasons), tilt the scanner and
look for the locking switch on the left corner at the back, then push the locking
switch to the "Locked" position. DO NOT turn the scanner upside down when
attempting to lock the unit.

Step 4: Connecting the Scanner

To the Power Adapter

1. Connect one end of the power adapter to the back of the scanner.
2. Plug the other end of the power adapter into a power source.
12 Spector-AF10 User's Manual
the locking switch at the bottom.
icon on the lock showing as "Unlocked".
Unlocked Locked
