5-2 System Menu Configuration

5-2 System Menu Configuration

This section describes items and functions displayed in the system menu.
The following items and functions are displayed in the system menu.
Group Name
Special Screen
Transfer
External Application
Initialization/Setting
Screen
System Language
Data Check
Numeral & String
Input Mode
Exit
Window Size
N o t
N o t
N o t
From the system menu of NS-Runtime it is possible to start up the CX-Programmer and the
SwitchBox Utility whose functions are equivalent to those of NS series Device Monitor, Ladder
Monitor, Programming Console and PLC data trace.
5-4
Menu Name
Alarm/Even History
Operation Log
Error Log
Communication Test
System Version
Screen Transfer
CX-Programmer
SwitchBox Utility
Initialization/Setting
Select Language
Data Check
Key on Screen
End NS-Runtime
Shut Down
Full screen display
Maximize
Minimize
Show Window
e
e
e
Function
Displays the alarm history.
Displays the operation log.
Displays the error log.
Checks whether communications
with a specified destination are
possible or not, by sending and
receiving FINS messages.
Displays the version display
screen.
Displays the screen data transfer
window.
Starts up CX-Programmer.
Starts up SwitchBox Utility.
Initializes data and makes settings
for the PT, project, password and
communications.
Switches the system language.
Checks screen contents by
displaying the registered screen
without communicating.
Selects the keypad or hardware
keyboard to input numerals and
strings to functional objects.
Ends NS-Runtime.
Ends NS-Runtime and shuts
down Windows.
Displays the NS-Runtime main
window in a full screen.
Maximizes the NS-Runtime main
window.
Minimizes the NS-Runtime main
window.
Displays the NS-Runtime main
window in the specified size.
Section
5-3-1
5-3-2
5-3-3
5-3-4
5-3-5
5-4
5-5-1
5-5-2
5-6
5-7
5-8
5-9
5-10-1
5-10-2
5-11-1
5-11-2
5-11-3
5-11-4
