7-3 Error Messages and Countermeasures

7-3 Error Messages and Countermeasures
This section describes the countermeasures for errors that are peculiar to the NS-Runtime.
For information on other error messages, refer to 5-2 Error Messages in the NS Series
Programming Manual and the Error messages and Countermeasures in the CX-Designer
Online Help.
Messages displayed on the CX-Designer.
The project for conversion does
not support xx. Cancel the
setting of xx before converting.
Process was aborted because a
setting that cannot be converted
was found. For details, refer to
the Output Window.
Only one document display can
be placed in a screen.
A document display cannot be
created on a sheet.
The object that cannot be
arranged on the pop-up screen
is contained.
Some objects cannot be pasted
on the frame.
The Document Folder Path is
not set.
Specify the Save Cycle to
between 1 second and 24
hours.
Destination folder is not set.
7-4
Message
Attempted to convert a project
for which the serial port A/B
was set to one of the following
settings to NS-Runtime.
-Host type other than SYSMAC-
PLC
-Temperature Controller
-Memory Link
-Barcode
-Modem connection
-General-purpose protocol
Attempted to convert a project
for which the host type
connected to Ethernet was not
SYSMAC-CS/CJ or SYSMAC-
CV to NS-Runtime.
Attempted to convert an NS-
Runtime project with more than
50,000 records in a normal log
to an NS-series project.
Attempted to convert an NS-
Runtime project with macros
supported only by the NS-
Runtime to an NS-series
project.
Attempted to place two or more
document display objects on
one screen.
Attempted to place a document
display object on a sheet.
Attempted to place a document
display objects on a pop-up
screen.
Attempted to place a document
display object on a frame
object.
Document folder path has not
specified in a Document Table
Setting Dialog Box.
Value out of range has been set
for the save cycle of the Internal
Holding Memory in the System
Setting Dialog Box.
On the system setting dialog
box, the save destination of
history data has not been
selected yet.
Cause
Convert a project for which the
serial ports are set to the
SYSMAC-PLC, or convert a
project for which the serial ports
are set to be not used.
Convert a project for which the
host type connected to Ethernet
is SYSMAC-CS/CJ or SYSMAC-
CV.
Change the log so that it
contains less than 50,000
records and attempt the
conversion again.
Delete macros that can be used
only for NS-Runtime and attempt
the conversion again.
Only one document display can
be created on each screen.
Create a document display
object on a base screen.
Create a document display
object on a base screen.
Create a document display
object on a base screen.
Specify a path.
Set a value to between one
second and 24 hours for the
save cycle.
Specify a path.
Possible Countermeasure
