Omron NS-RUNTIME - SOFTWARE User Manual page 106

5-6 Initialization/Setting Screen
Saving the Operation Log
Saving the latest history data on a specified drive in CSV file with the following name.
Operation log data: Operat_yymmdd_hhmmss.csv
Operat_yymmdd_hhmmss.CSV
1. Click the Save Button for the operation log. A confirmation message will be displayed.
Click the Yes Button to save the data. Click the No Button to cancel the save function.
2. When operation log saving has been completed, the following dialog box will be displayed.
3. If the operation log saving has failed, the following dialog box will be displayed.
N o t
N o t
N o t
When saving the operation log, the operation log must be controlled from the system memory.
For details on controlling the operation log, refer to 2-4 System Memory in the NS Series
Programming Manual.
Initializing and Saving the Error Log
This function is used to initialize the macro error history saved in the NS-Runtime or save the
history in a removable drive.
Up to 100 errors can be recorded in the error log. The number of errors that can be recorded,
however, also depends on the free space in the memory.
5-22
Date when the file is saved (year, month, and day)
e
e
e
Time when the file is saved (hour,
minutes, and seconds)
Fixed character string
