Omron NS-RUNTIME - SOFTWARE User Manual page 127

2. When selecting the Enable, set and display the Controller Link details. To change the
settings, use UP and DOWN Buttons, or the keypad that is displayed by clicking the
keyboard button.
No Item
1 Network Address
2 Node Address
3 Comm. Speed
3. After setting, click the Write Button to save the setting. (For details on the write button,
refer to Writing on page 5-29.)
4. The settings are enabled after The NS-Runtime is restarted.
Function
Sets and displays the local network
address.
Sets the local node address.
Sets the baud rate.
5-6 Initialization/Setting Screen
1
2
3
Setting Range
Read-only
1 to 254
500K, 1M, 2M
5-43
